Status - Network

Name
NIC 1 / NIC 2
MAC address
IP address
Sync port
GMID
Hyperlinks
Name / IP address (p 38)
Mouse over:
LED NIC 1 - indicating link state and connection speed
LED NIC 2 - indicating link state and connection speed
N OT E
If NIC 1 and NIC 2 are connected to the same switch, they must be configured to
different subnets - see "Network Settings" on page 38.
EXBOX.RAV Manual - Version 1.0
Module's name in the network. Used e.g. for mDNS
service. The name needs to be unique throughout the
network.
Monitoring state of network interface controller (NIC)
(OFF) = not connected
(ON) = connected with the network
Hardware identification of NIC.
IP address of device
Selected port for PTP sync
Grand Master ID (PTP)
