Transfer sling

Advertisement

Quick Links

QUICK REFERENCE GUIDE - USE
Sara 3000
(
For more information on slings, please read the sling documentation.)
1
NOTE
Do not use the leg
Lean the patient forward and place
the sling around their lower back,
5 cm (2 inches) above their waste
line.
5
Apply the clips to the attachment
points. Pull the clips as shown to
secure them.
2
A
Make sure that the support strap is
separated.
Take each leg section (A) of the
sling and slide under each leg.
6
B
A
Attach each attachment loop (A)
on each leg-side (left and right) on
the central lug (B).
ABR81010.EN.M_06 • 09/2020 • Page 1/4
3
Press the buckles (if available) or
hook and loop strap (if available)
together.
Tighten the strap so that it is
comfortable for the resident.
7
A
Place the residents feet on the
foot support (A).
4
Move Sara 3000 into position.
8
NOTE
A
