Arjo Sara 3000 Quick Reference Manual

QUICK REFERENCE GUIDE
Sara 3000
This Quick Reference Guide has been produced to assist Healthcare
Professionals and other users with only the functional aspects of the
system. The guide does not replace the general safety warnings, cautions
and recommendations provided in the product instructions for use, part
number KKX81010M-EN.
Refer to the product instructions for use before using this product.

Product Overview

1. Fit the sling to the resident, ensuring correct size is used. Ensure chest strap is fastened securely and
residents arms are outside the sling.
2. Position the SARA 3000 in front of the resident, open the chassis legs if necessary, assist in placing
residents feet on the foot support with the knees touching the kneepad and allow resident to hold
hand grips.
3. Adjust height of resident support arms to its lowest position.
4. Attach the sling to the SARA 3000 and put under tension before lifting.
5. Using the handset or dual control, raise the resident to a standing position.
6. Close legs and transport resident to chair, bed or toilet.
7. Position the resident in front of chair, bed or toilet with the back of their legs gently touching e.g. the
chair and lower to a sitting position.
8. Release tension on the sling and remove sling from the SARA 3000.
9. Remove the SARA 3000, taking care to remove the residents feet from the foot support.
10. Remove the sling from around the resident.
Pull the Clip attachments in the
direction of the arrow
up/down
Use the handset to move the
resident support arms
Chassis
open/close
If necessary, pull up the
Emergency lowering knob
ABR81010.EN.M_05 · 08/2019
If necessary, push the red
emergency stop button
