Tiger 320 Series Code Logic Diagram - Texmate Tiger 320 Series Programming Manual

Code Version v3.09b
Tiger 30 Series Code Logic Diagram
P
To enter press the and
buttons at the same time
Main Programming Mode
Display Brightness
[bri]
Allows you to adjust the display brightness in a range of 8 settings. 0 being
P
dull, 7 being bright.
Calibration Modes for Input and Output
[CAL]
See Page 2 for code settings to calibrate the meter's input and output signals.
P
Code  – Display Configuration
[Cod_]
See Page 3 for code settings to configure the setpoint annunciators and other
P
display functions.
Code  – CH Measurement Task & Sampling Rate
[Cod_]
See Page 4 for code settings to configure the CH1 measurement task and
P
sampling rate.
Code 3 – CH Post Processing & Serial Mode Functions
[Cod_3]
See Page 5 for code settings to configure CH1 post processing and serial
P
mode functions.
Code  – CH Measurement Task & 3-point Linearization
[Cod_]
See Page 5 for code settings to configure the second channel (CH2) mea-
surement task and 32-point linearization settings when using dual input signal
P
conditioners.
Code 5 – CH3 Functions
[Cod_5]
See Page 5 for code settings to configure the third channel (CH3) when
P using triple input signal conditioners.
Code 6 – CH Functions
[
Cod_6]
See Page 6 for code settings to configure the fourth channel (CH4) when
using quad input signal conditioners.
P
Code 7 – Result Processing
[Cod_7]
See Page 6 for code settings to configure the meter for processing the result
P
of CH1 and CH2.
Code 8 – Data Logging & Print Mode
[Cod_8]
See Page 6 for code settings to configure data logging and data printing
P
using the meter.
Code 9 – Functions for Digital Input Pins
[Cod_9]
See Page 6 for code settings to configure the meter for inputs from external
sources through the digital input pins.
P
Code 0 – Bargraph Setup
[Cod0]
See Page 7 for code settings to configure the meter's bargraph display.
P
Prog.
SP1 SP2 SP3 SP4 SP5 SP6
Operational Display
May 26 2009 PCS v3.09b (NZ101)
To enter press the
buttons at the same time
Prog.
SP1 SP2 SP3 SP4 SP5 SP6
Operational Display
Setpoint Programming Mode
Texmate Inc. Tel. (760) 598 9899 • www.texmate.com
P
and
Setpoint Activation Values Mode
Enter these menus to set setpoint
(SP) activation values
Setpoint  Default setting = 18000
[SP_]
P
Setpoint  Default setting = –18000
[SP_]
P
Setpoint 3 Default setting = 5000
[SP_3]
P
Setpoint  Default setting = –5000
[SP_]
P
Setpoint 5 Default setting = 10000
[SP_5]
P
Setpoint 6
[SP_6] Default setting = –10000
P
Setpoint & Relay Control Settings Mode
Enter these menus to configure SP control
settings
[SPC_] Setpoint
The Setpoint and
Relay
P
Settings diagram
[SPC_] Setpoint
on Pages 8, 9, and
0 shows the three
P
digit configuration
[SPC_3] Setpoint 3
settings that are
applied individually
P
to each setpoint.
[SPC_] Setpoint
P
[SPC_5] Setpoint 5
P
Setpoint 6
[SPC_6]
P
Prog.
SP1 SP2 SP3 SP4 SP5 SP6
Operational Display
Tiger 320 Series Programming Code Sheet
E/T Versions of Tiger 30 Series Programmable Meter Controller
Tiger 320 Series Programmable Meter Controllers (PMCs) come in
two versions: the economy E version, or the top-of-the-line T version.
The standard E version comes with 4 kilobits of EEPROM installed,
whereas the standard T version comes with 32 kilobits of EEPROM
Installed. Also, the T version can have a macro installed.
The standard 4-kilobit E version can be upgraded to 32 or to up to
1024 kilobits. The standard 32-kilobit T version can be upgraded to
1024 kilobits. The amount of EEPROM installed in the controller deter-
mines the range of functions it is capable of performing. The following
table lists the functions that require specific amounts of memory.
Version Memory
(kilobits)
E 4 (standard) 1 linearization table
32 4 linearization tables
up to 1024
Control
T 32 (standard) 4 linearization tables
Macro programming
up to 1024
Functions Remarks
Table 1 is available to
be applied to chan-
nels 1 to 4 and result.
Tables 1 to 4 are
available to be
applied to channels 1
and 2 and result.
Table 3 can be applied
to channel 3.
Table 4 can be applied
to channel 4.
All four tables can be
cascaded to form a
single 125-point lin-
earization table avail-
able to be applied to
channels 1 and 2 and
result.
With up to 1024
Data logging
kilobits installed,
the controller can
perform data logging
functions along with
complete linearization
functionality. With
a real-time clock
installed, date and
time stamps can be
included.
As for E version with
32 kilobits installed.
A macro can be pro-
grammed to suit a
user's logic control
application.
Data logging As for E version with
up to 1024 kilobits
installed, but with
macro programming
functionality available.
