Texmate Tiger 320 Series Programming Manual page 3

Code Version v3.09b
Code Blanking and Macro Check
Tiger 320 Series meters have the ability to hide (blank out)
all or some programming codes, making them tamper-proof.
This can only be done using the Meter Configuration Utility
program.
With code blanking turned ON, all main and setpoint codes
that have been blanked out during factory programming are
hidden, preventing them from being reprogrammed. Any
codes that have not been blanked out are still visible and can
be reprogrammed.
Turning code blanking OFF means all meter programming
codes are visible when you enter the programming modes
and can be reprogrammed.
A macro is a set of commands that run automatically when
the meter is powered up. Texmate has a growing library of
macros to suit a wide range of standard customer applica-
tions.
Macros can be installed in the meter at the factory dur-
ing initial programming or by the customer at some later
date. Macros are written and compiled using the Tiger
Development System (TDS) compiler program, and loaded
into the meter using either the compiler program or the con-
figuration program.
Turning the macro OFF means that the meter will not perform
the automatic commands pre-programmed to run with the
macro.
Unless requested to blank out all or some programming
codes and/or run a macro, Texmate program the meter in the
code blanking OFF and macro ON (default) setting.
To turn the code blanking and macro settings from ON to
OFF carry out the following procedure:
Programming Tip
Code Blanking and Macro ON/OFF settings
revert to the meter's original configuration set-
tings when the meter is powered off and on.
May 26 2009 PCS v3.09b (NZ101)
CODE BLANKING & MACRO CHECK PROCEDURE
CODE BLANKING & MACRO CHECK PROCEDURE
Operational Display
START HERE
TEXMATE
Step 1
Press and hold
Prog.
the and
buttons
TEXMATE
Step 2 Step 2
Prog.
While holding both While holding both
buttons, press the Prog. buttons, press the Prog.
button. button.
TEXMATE
Prog.
Step 3
Release
Release the
after 1
the and sec
buttons and hold
the Prog. button
TEXMATE
for approx. 1 sec
then release
Example
Prog.
SP1 SP2 SP3
TEXMATE
NOTE: Unless otherwise
requested, the factory
default setting is oFF
Prog.
Step 4
Code Blanking & Macro
Check Procedure
Press the button to switch
continued in (Step 5)
code blanking oFF
Texmate Inc. Tel. (760) 598 9899 • www.texmate.com
CODE BLANKING & MACRO CHECK PROCEDURE 1
continued from Step 4
Press
and
SP1 SP2 SP3 SP4 SP5 SP6
hold Step 5
Press the Prog. button.
Release
after
SP1 SP2 SP3 SP4 SP5 SP6
pressing
Prog.
NOTE: Unless otherwise
requested, the factory
default setting is on.
Step 6
Press the button to switch
the macro OFF
SP1 SP2 SP3 SP4 SP5 SP6
Step 7
Code
Blanking
Press the Prog. button.
SP4 SP5 SP6
Press
SP1 SP2 SP3 SP4 SP5 SP6 1
Tiger 320 Series Programming Code Sheet
TEXMATE
Prog.
SP1 SP2 SP4 SP5 SP6
SP3
Press
1
TEXMATE
Example
Macro
Prog.
SP1 SP2 SP3 SP4 SP5 SP6
TEXMATE
Prog.
SP1 SP2 SP3 SP4 SP5 SP6
TEXMATE
Prog.
SP1 SP2 SP4 SP5 SP6
SP3
Press
1
TEXMATE
Prog.
SP1 SP2 SP3 SP4 SP5 SP6
Operational Display
Press
1
3
