OPERATION AND MAINTENANCE INSTRUCTIONS
DESMI portable centrifugal pump
SA50-T (50-135/14) HATZ 1B20/30
DESMI PUMPING TECHNOLOGY A/S
Tagholm 1 – DK-9400 Nørresundby – Denmark
Manual:
Special pump No.:..........................
Tel.: +45 96 32 81 11
Fax: +45 98 17 54 99
E-mail:
Internet:
Language:
T1411
English
desmi@desmi.com
www.desmi.com
Revision:
F (11/19)
