DESMI Vertical In-Line Centrifugal Pump
OPERATION AND MAINTENANCE INSTRUCTIONS
Tagholm l, DK-9400 Nørresundby, Denmark
Manual:
T1542
Special pump Number. ...............................................
NSL MONOBLOC & SPACER
DESMI Pumping Technology A/S
Tel.: +45 96 32 81 11
Fax: +45 98 17 54 99
E-mail:
Internet:
Language:
English
desmi@desmi.com
www.desmi.com
Revision:
A.1
Original instructions
