- Page 1 PROGUARD Coffee Instructions | Replacement of Pump (Non-electric)
- Page 2 Note: During the replacement of the non- electric pump, the coffee machine can neither be supplied with filtrate nor bypass water. Required tooling: - Bucket - Screwdriver Phillips head (№ 2) - Collet locking tool 1/4"...
- Page 3 Close the shutoff valve...
- Page 4 Remove the front panel...
- Page 5 Open the locking handle of the filter head...
- Page 6 Open the sampling valve Empty the storage tank Close the sampling valve...
- Page 7 Demount the rear panel (5 screws)
- Page 8 Demounting of the pump used: Remove the locking clips (4x); keep them safe...
- Page 9 Pull the fittings (4x) from the hoses...
- Page 10 Pull the pump out of its holder Remove the remaining locking clips (4x) and keep them safe (8x in total)
- Page 11 Remove the nipples from the new pump...
- Page 12 Mounting of the new pump: - Insert the included hoses (4x) into the pump - Secure their position with the locking clips...
- Page 13 Important: The sticker must not point outwards Important: The fins must not be on the right side...
- Page 14 Important: The fittings must not be connected to the incorrect hoses...
- Page 15 Connect the fittings with the hoses (4x) Attach the locking clips (4x) that you have saved Push the pump into its holder...
- Page 16 Important: Position the fittings vertically to each other...
- Page 17 Correct positioning of the pump...
- Page 18 Open the shutoff valve...
- Page 19 Close the locking handle of the filter head Now, the filtrate production will restart Check the system for leakages...
- Page 20 Remount the rear panel (5 screws)
- Page 21 Hook the front panel back into its place Done! You successfully replaced the pump...
