QUICK REFERENCE GUIDE - USE

Maxi Sky 1000

Lift from seated position

Place the sling around the patient,

with the base of the sling slightly

below the tail bone.

For sling with head support extend

to top of patient's head.

Place attachment loop on the

hook.

Loop sling

Make sure the safety latches are

closed and the sling strap is

completely inside the hook.

001-01392-EN Rev 0 • 06/2020 • Page 1/4

Pull each leg strap under the thigh so that it

emerges on the inside of the thigh.

Approach the patient with the lift.

Place the spreader bar in sitting position.

Place the spreader bar at or just below shoulder

level.

Place the spreader bar close enough to

be able to attach the shoulder straps.

Connect the sling loops to the spreader bar.

Attach shoulder straps then leg straps.

Raise the patient, proceed with the transfer.

Lower onto new location. When body

weight is fully supported detach loops.

Need help?

Do you have a question about the Maxi Sky 1000 and is the answer not in the manual?

Page 1 QUICK REFERENCE GUIDE - USE Maxi Sky 1000 Lift from seated position Place the sling around the patient, Pull each leg strap under the thigh so that it with the base of the sling slightly emerges on the inside of the thigh.
Page 2 Transfer from supine position Roll the patient onto their side. Fold the Roll the patient back onto the sling and then roll the patient in the sling in half and place it on the bed along opposite direction, so that the folded part of the sling can be the back of the patient.
Page 3 Lift from seated position - Bariatric sling application Place attachment loop on the Place the sling around the patient, with the hook. base of the sling slightly below the tail bone. Loop sling For sling with head support extend to top of Make sure the safety latches are closed and the sling strap is patient’s head.
Page 4 Raise the patient in a semi-reclined position for the transfer. Lower onto new location. When body weight is fully supported detach loops. ArjoHuntleigh AB Hans Michelsensgatan 10 211 20 Malmö, Sweden www.arjo.com 001-01392-EN Rev 0 • 06/2020 • Page 4/4...
