Nomenclature And Specifications; Compressor Nomenclature; Frequency Converter Nomenclature - Danfoss VZH Series Application Manuallines

Application guidelines

Compressor nomenclature

Variable speed
Family
VZH scroll
Lubricant
POE lubricant, R410A
refrigerant
Swept volume
in cm³/rev
Design pressure ratio
A: high PR,
B: low PR
Frequency converter
nomenclature
Dedicated compressor
drive for VZH/VSH scroll
Serie 303
High overload
output power
in kW
Note:
High overload output power: output power @160% Torque
Normal overload: output power @110% torque, it is the power printed in the nameplate.
For example:
T/C: CDS303P15KT4E20H2-P15K high overload output power, take the reference of drive nomenclature
18.5kW(400V)-normal overload power, power printed in the nameplate.
Please note in this guideline, only drive power use high overload power; all the other data, such as fuses/circuit breaker, etc. is reference to Normal overload power.
8
FRCC.PC.023.A7.22

Nomenclature and specifications

V Z H 117
CDS 303 P15K
A G A N
T4 E20
Single compressors
A
Evolution index
Motor protection type
N: no internal motor protection
(protection by drive)
Equipement version
A: brazed connections, single version
B: brazed connections, manifold version
Oil sight glass
Single version Threaded
Manifold version None
Motor voltage code to CDS303 *
G: 380-480V/3~/50 & 60Hz
H: 525-600V/3~/50&60Hz
J: 200-240V/3~/50 & 60Hz
* main supply voltage to frequency converter
H2
RFI class
Enclosure protection
IP rating
Main supply voltage
T2: 200-240V/3 ph/50-60 Hz
T4: 380-480V/3 ph/50-60 Hz
T6: 525-600V/3 ph/50-60 Hz
Oil level switch
None
Threaded
