Application guidelines

VZH088-J single version

8.69
Suction
1"1/8
18.49
max.
6.18
Ø9.57
8.64
3.62
0.59
with compression
30°
4 holes
Ø0.75
6.22
9.05
7.5
60°
30°
Dimensions
Ø8.82
Discharge
7/8"
17.17
3.1
7.16
9.05
7.5
7.89
6.06
7.91
Electrical box
Ø 16.5 mm
knockout

VZH088-J manifolded version

18.49
max.
Ø8.69
Suction
1"1/8
6.18
Ø9.57
3.62
0.59 with
compression
oil equalisation
Ø32 - 1.75"
12UN - 2A
4 holes
Ø0.75
9.05
7.5
60°
30°
Grommet
Lock washer
Flat washer
Steel mounting
sleeve
Ø 40.5 mm hole
Rubber grommet
Power supply
Single compressors
Ø8.82
Discharge 7/8"
2.35
9.05
7.5
30°
7.11
6.22
All dimensions in inch
HM 8 bolt
Nut
FRCC.PC.023.A7.22
17.17
8.64
3.1
6.06
0.59 inch
