Mocka Nava Four Drawer Assembly Instructions Manual page 2

Nava Four Drawer
Assembly Instructions
1
3
E
F
E
C
E
CR
G
E
E
G
E
C
Attach 4x slide rails (F) and 4x slide rails (G) to panels [3] and [4] as shown
with 24x screws (E). Insert 8x bolts (C) into panels [3] and [4]. Tighten with
a screwdriver.
