ZyXEL Communications LTE7485-S905 Quick Start Manual

LTE7485-S905
4G LTE-A Outdoor Router
Quick Start Guide
Location Examples Location Examples Location Examples
Location Examples
Pole Mounting
Pole Mounting
Pole Mounting
Place the LTE7485-S905 in an open
area free of obstacles, and adjust the
Smartphone
Pole Mounting
angle to point it towards the base
station to have the strongest possible
LTE signal.
Step 1
SIM Card Installation
1
LAN (PoE)
1 Make sure the LTE7485-S905 is turned off. There should be no Ethernet cable connected
providing power using PoE. Unscrew the SIM card slot cover and remove it.
Step 2
Cable Connections
1
1-4 Follow steps 1 to 4 in the drawing to connect an 8-pin Cat 5e Ethernet cable to the LTE7485-S905's LAN port.
1/4
Power Outlet
PC
Gateway
Notebook
Gateway
Smartphone Laptop
2
Package Contents Package Contents Package Contents
LTE7485-S905 LTE7461-M602 LTE7461-M602 Power Power
Cord Cord Cable
Mounting Kit
x4 x4
x4 x4
x6
M6 Spring M6 Spring Hex Nuts Hex Nuts
M6 Washers M8 Washers
Washers Washers
& Washers & Washers
x4
Nylon Wall Tapping Screws
Plugs M4x25 mm
See the User's Guide at www.zyxel.com for more information,
including customer support and safety warnings.
