LTE3311 Series
LTE Indoor Gateway
Version 1.00
Edition 1, 06/2015
Quick Start Guide
Default Login Details
LAN IP Address
User Name
Password
www.zyxel.com
http://192.168.1.1
admin
1234
Copyright © 2015 ZyXEL Communications Corporation

Advertisement

loading
Need help?

Need help?

Do you have a question about the LTE3311 Series and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications LTE3311 Series

Summary of Contents for ZyXEL Communications LTE3311 Series

  • Page 1 LTE3311 Series LTE Indoor Gateway Version 1.00 Edition 1, 06/2015 Quick Start Guide Default Login Details LAN IP Address http://192.168.1.1 User Name admin Password 1234 www.zyxel.com Copyright © 2015 ZyXEL Communications Corporation...
  • Page 2 Panels POWER ANTENNA ANTENNA ON/OFF RESET CONNECTOR2 CONNECTOR1 BUTTON BUTTON PORTS 1-4 USIM/SIM PHONE CARD SLOT DC POWER IN WPS ON/OFF BUTTON...
  • Page 3 Requirements Make sure you have the following before you start: • INTERNET ACCESS: You need a SIM card from an LTE ISP (Internet Service Provider). You may also need a PIN code, APN, or IP address to use the SIM card. •...

  • Page 4: Hardware Connections

    Hardware Connections Make sure the LTE3311 is off and follow the steps listed below for the hardware connections. 1. Install the antennas. 2. SIM CARD: Insert your SIM card to the SIM card slot for the LTE network access. 3. LAN: Use an Ethernet cable to connect a computer to one of these ports for initial configuration and/or Internet access.
  • Page 5 4. POWER: Use the power adaptor provided with your LTE3311 to connect an appropriate power source to this socket. 5. Push in the power button to turn the power on. 6. USB: Connect the USB device to the LTE3311’s USB port for sharing files.
  • Page 6 • The WLAN/WPS light stays on and green when the 2.4GHz band wireless LAN is ready. The light will not turn on if the wireless connection is not activated. It blinks orange per 0.5 seconds after you press the WPS button. The process takes up to 2 minutes within which you can add a WPS-enabled device to the wireless network.

  • Page 7: Set Up A Wireless Connection

    Set Up a Wireless Connection The LTE3311’s wireless LAN is enabled by default. Use the wireless SSID (network name) and encryption key on the back panel to manually add a wireless client to the network. Refer to the User’s Guide if you wish to use WPS (Wi-Fi Protected Setup) instead.
  • Page 8 2. Select the LTE3311’s SSID name and click Connect (A). The SSID “SecureWirelessNetwork” is given here as an example. 3. When prompted for a password, enter the (WPA2-PSK) encryption key from the back panel of the LTE3311 and click Connect. 4.
  • Page 9  If you cannot connect wirelessly to the LTE3311, check that you selected the correct SSID and entered the correct security key. Make sure the LTE3311’s WLAN is enabled and the WLAN/WPS LED is on.

  • Page 10: Connect To The Internet

    Connect to the Internet 1. Open your browser and go to http://192.168.1.1. • If your service provider’s LTE login page appears instead of your default Home page then all you need to do is enter the login information that you were given and follow the on- screen instructions.
  • Page 11 3. Change a new password. 4. If the INTERNET light is off, manually configure the Internet connection. Click Configuration > Network > WAN and then the Modify icon. The APN identifies the LTE network to which your LTE Modem connects. 5.
  • Page 12 6. Wait for the INTERNET light to turn on and then try browsing to a website. • For more information see the WAN section in the User’s Guide. • To configure wireless access, go to Configuration > Network > Wireless LAN.

  • Page 13: Using The Wizard

    • To set up WPS using the Web Configurator, go to Configuration > Network > Wireless LAN > WPS. Using the Wizard You can use the wizard to quickly configure your login password, time zone, the WAN and WLAN settings. 1.
  • Page 14 3. The system automatically detects your time zone. If the result is not correct, press Detect Again or select a proper one manually. Click Next. 4. Select the Country and the Service Provider, and the corresponding APN name will display in the APN Name field. If the field displays wrong name, specify the right APN name in the APN Name field.
  • Page 15 5. Configure the wireless LAN settings and then click Next. 6. Configure the wireless security settings and then click Next.
  • Page 16 For more information, please refer to the User’s Guide at the www.zyxel.com download library. Network standby power consumption < 12W Off mode power consumption < 0.5W EU Importer: ZyXEL Communication A/S, Generatorvej 8D, 2860 Søborg, Denmark. http:// www.zyxel.dk US Importer: ZyXEL Communications, Inc | 1130 North Miller Street Anaheim, CA 92806-2001 | http://www.us.zyxel.com...
  • Page 17 Your product is marked with this symbol, which is known as the WEEE mark. WEEE stands for Waste Electronics and Electrical Equipment. It means that used electrical and electronic products should not be mixed with general waste. Used electrical and electronic equipment should be treated separately.
