6300 Series Full Feature Low Energy Operator
Models 6332 (Push Side)
Installation Instructions
WARNING
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65warnings.ca.gov.
6332 Push Side 110° to 135° opening
End Cap Kit
(6300END)
Tools Needed
#7
1/4-20
3/8"
10" or 12"
#2 and #3
Copyright © 2019, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9363-0009-020 Rev 3 12/19
Power Supply
(6300CM2)
Backplate
9/32"
3/16"
3/32"
3/16"
3/4"
Deep
Well
Punch
1/2"
Pour la version francaise voir www.nortondoorcontrols.com.
READ AND FOLLOW ALL INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
Cover (6300COV)
Push Arm Pkg
(6330-1)
Supplied Fasteners
End Cap Kit
(6300END)
Closer Body
(6300LAP)
