6200 Series Full Feature Low Energy Operator
Models 6231 (Push Side), Low Ceiling Application
Installation Instructions
WARNING
This product can expose you to lead which is known to the
state of California to cause cancer and birth defects or other
reproductive harm. For more information go to:
www.P65warnings.ca.gov.
6231 Push Side up to 130° opening
Optional
Power Cord/ Surface
Conduit Bracket
(6300CBPC or 6300CB)
End Cap Kit
(6300END)
Dress Plate (6300DPS)
Tools Needed
1/4-20 9/32"
#7 3/8"
2.5mm
10" or 12"
Wire
#2 & #3
Stripper
The table below provides a list of documents associated with this product. These documents are available for download
from www.nortonrixson.com. If additional information or assistance is needed, contact Technical Product Support.
6200 Series Quick Start Guide
6200 Series Operator On Board or WiFi Programming Guide
6231 Push Side, Low Ceiling Application Template, 36-48" Door Width, 90-200 lb. Door Weight
130° Max Open Angle w/ Reveal of 1/8" to 3-1/4"
Copyright © 2022-2025, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9363-0020-020 Rev 4 03/25
Power Supply
(6200CM)
Push Arm Pkg
Backplate
Pair
Safety
Glasses
Punch
3/32"
Ø7/8 Drill or
3/16"
Hole Saw
3/4"
Deep
Well
1/2"
Pliers
Document Title
Approved 2025-03-13
(7701-1)
Supplied Fasteners & Tools
or
12x
2x
Backplate &
Zip
Forearm Shoe
Ties
1/4-20 Machine
or
1/4-14 x 1-3/4"
Wood
4x
Operator Body
1/4-20 x 3-3/4"
Pour la version francaise voir NortonRixson.com.
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
Operator Body
(6200LAP)
1x
Main Arm
1/4-20 x 1/2"
6x
Power Supply
& End Caps
1/4-20 x 3/8"
2x
Forearm Shoe Option
1/4-20 x 5/8"
Screw & Sleeve Nut
Document Number
80-9363-0021-020
80-9363-0022-020
80-7362-0001-020
Cover
(6300COV2 or
6300COV2-CB)
4x
8-32 X 5/16"
1x
Cable
2x
Retaining Clip
Optional
8-32 x 1/4"
Machine
Screw
2x
Cable Retaining
3/16" 5/32"
Clips
