6200 Series Full Feature Low Energy Operator
Model 6211 (Pull Side)
Installation Instructions
WARNING
This product can expose you to lead which is known to the
state of California to cause cancer and birth defects or other
reproductive harm. For more information go to:
www.P65warnings.ca.gov.
6211 Pull Side Up to 120° opening
End Cap Kit
(6300END)
Pair
Standard Pull
Arm Pkg
Tools Needed
1/4-20 12-24
#7 #16
2.5mm
10" or 12"
#2 & #3
Stripper
The table below provides a list of documents associated with this product. These documents are available for download
from www.nortonrixson.com. If additional information or assistance is needed, contact Technical Product Support.
6200 Series Quick Start Guide
6200 Series Operator On Board or Wi-Fi Programming Guide
6211 Pull Side Template, 36-48" Door Width, 90-200 lb. Door Weight, 120° Max Open Angle
Copyright © 2022, 2023, 2025, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9363-0023-020 Rev 3 01/25
Backplate
Operator Body
(6200LAP)
Track
(6210-1)
(7100-1T)
Safety
Glasses
9/32" 3/32"
3/8" 3/16"
Ø7/8 Drill
Hole Saw
3/4"
Deep
Wire
1/2" Well
Pliers
Document Title
Approved 2025-01-28
Power Supply
(6200CM)
Supplied Fasteners & Tools
3x
Track Option
Zip #12-24 x 1-3/4"
or Ties Sleeve Nut & Bolt
4x
Operator Body
Punch 1/4-20 x 3-3/4"
Pour la version francaise voir NortonRixson.com.
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
Optional
Power Cord/
Surface Conduit Brackets
(6300CBPC or 6300CB)
3/16"
2x 12x
14-14 x 1-3/4"
Self-drilling
Screw Machine Screw
6x 12x
Power Supply 1/4-20 x 5/8"
& End Caps Machine
1/4-20 x 3/8" Screws w/ Nylon Patch
Document Number
80-9363-0021-020
80-9363-0022-020
80-7362-0002-020
Cover
(6300COV2 or
6300COV2-CB)
5/32"
1x
Cable
2x
Retaining Clip
Optional
8-32 x 1/4"
1x
2x
Arm
Cable Retaining
1/4-20 x 3/4"
Clips
