Assa Abloy Norton 6300 Series Installation Instructions Manual

6300 Series Full Feature Low Energy Operator
Models 6311, 6351 (Pull Side)
Installation Instructions
WARNING
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65warnings.ca.gov.
6311 Pull Side Up to 180° opening
End Cap Kit
(6300END)
Backplate
6351 Pull Side Double Egress Up to 130° opening (Right Hand Shown)
Double Egress
Pull Arm Pkg
(6350-1L (LH);
6350-1R (RH)
Tools Needed
#7
1/4-20
10" or 12"
#2 and #3
Copyright © 2019, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9363-0005-020 Rev 4 12/19
Closer Body
(6300LAP)
Standard Pull Arm Pkg
(6310-1)
#16 12-24
3/16" 3/32"
3/4"
Deep
Well
1/2"
Pour la version francaise voir www.nortondoorcontrols.com.
READ AND FOLLOW ALL INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
Track
(7100-1T)
Supplied Fasteners
3/16"
Punch
Cover (6300COV2)
End Cap Kit
(6300END)
Power Supply
(6300CM2)
