- Page 1 © KROHNE 07/2000 Supplementary Installation and Operating Instructions BM 100 A KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg Tel.: 0203-301 309 Fax: 0203-301389 · e-mail: krohne@krohne.de...
-
Page 2: Table Of Contents
2.3 S ..........................6 HIELDING AND GROUNDING 2.4 PROFIBUS-PA ..........................7 CONNECTION 3. MENU SETTINGS FOR PROFIBUS-PA........................7 4. TECHNICAL DATA, PROFIBUS IDENT-NO. EE01 ....................7 KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg Tel.: 0203-301 309 Fax: 0203-301389 · e-mail: krohne@krohne.de... -
Page 3: General
Attention: Please set the controller to manual mode before changing parameters of the BM 100 A. Items included with supply In addition to the standard scope of supply, these Supplementary Instructions for the BM 100 A with PROFIBUS-PA interface plus a diskette with the available Profibus device data files (GSD files) of all KROHNE devices. -
Page 4: Profibus-Pa - Services
1.2.1 GSD file All available GSD files of KROHNE devices – including those of the BM 100 A, of course - are supplied together with each device. The GSD contains information that is needed for project planning of the PROFIBUS-DP/PA communication network. -
Page 5: Meaning Of Measurement And Status Information
The status should be watched always because a valid number will be transmitted even if the status of the measurement is bad or uncertain. This is the only chance to check the meaning of the transmitted measurement values. KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg Tel.: 0203-301 309... -
Page 6: Electrical Connection
In “Ex“ systems an adequate equipotential bonding in the hazardous and non-hazardous location along the entire fieldbus installation is strongly recommended. Multiple grounding of the shield is also of advantage. Note: The use of twisted and shielded cables is strongly recommended, otherwise EMC protection of the BM 100 A cannot be assured. -
Page 7: Profibus-Pa Connection
For a detailed description please check the Installation and Operating Instructions manual of the device. The following settings need to be made for operation of the BM 100 A on a PROFIBUS-PA network. Note that the service “set slave address” is not being supported. Therefore the address can only be set by way of the local display and operator interface.
