Vortex flowmeter
Equipment protection level EPL Gb / Db
in type of protection Flameproof enclosure "d" and
in type of protection Equipment dust-ignition protection by enclosure "t"
© KROHNE 01/2019 - 4007443601 - AD OPTISWIRL4200 EAC Exd R01 en
Supplementary Instructions
Supplementary Instructions
Supplementary Instructions
Supplementary Instructions

Advertisement

Table of Contents
loading

Related Manuals for KROHNE OPTISWIRL 4200

Summary of Contents for KROHNE OPTISWIRL 4200

  • Page 1 Supplementary Instructions Vortex flowmeter Equipment protection level EPL Gb / Db in type of protection Flameproof enclosure "d" and in type of protection Equipment dust-ignition protection by enclosure "t" © KROHNE 01/2019 - 4007443601 - AD OPTISWIRL4200 EAC Exd R01 en...

  • Page 2: Table Of Contents

    CONTENTS OPTISWIRL 4200 1 Safety instructions 1.1 General notes ........................3 1.2 TR CU conformity......................3 1.3 Approval according to the IECEx scheme ................ 3 1.4 Safety instructions......................4 2 Device description 2.1 Device description ......................5 2.2 Description code....................... 5 2.3 Marking..........................

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS OPTISWIRL 4200 1.1 General notes This additional instruction applies to explosion-protected versions of vortex flowmeters with protection type flameproof enclosure "d", increased safety "e" and equipment dust-ignition protection through enclosure "t", equipment protection level EPL Gb and EPL Db.

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS OPTISWIRL 4200 1.4 Safety instructions If these instructions are not followed, there is a risk of explosion. Assembly, installation, start-up and maintenance may only be performed by personnel trained in explosion protection! CAUTION! Operating conditions and place of installation may require compliance with additional standards, directives or laws.

  • Page 5: Device Description

    DEVICE DESCRIPTION OPTISWIRL 4200 2.1 Device description Vortex flowmeters measure and display the flow of flammable and non-flammable gases and ® liquids. The signal converter includes either a 4...20 mA signal output with optional HART communication or a bus connection. There are bus connections available for connecting to a Foundation Fieldbus or Profibus PA.

  • Page 6: Marking

    * positions which are not needed are omitted (no blank positions) The remote version consisting of the flow sensor OPTISWIRL 4000 F and the signal converter VFC 200 F 020 is called the OPTISWIRL 4200 F. 2.3 Marking The marking of the devices in accordance with the description code is shown on the nameplates below.
  • Page 7 DEVICE DESCRIPTION OPTISWIRL 4200 Figure 2-5: Example of the nameplates for the remote version 1 Device version VFC 200 F .. 020 / OPTISWIRL 4000 F 2 Production order number 3 Serial number 4 Year of manufacture 5 Ex data according to notified body...

  • Page 8: Flammable Products

    DEVICE DESCRIPTION OPTISWIRL 4200 2.4 Flammable products Atmospheric conditions: Atmospheric conditions: Atmospheric conditions: Atmospheric conditions: The standard atmospheric conditions under which it may be assumed that Ex equipment can be operated are: • Temperature: -20...+60°C / -4...+140°F • Pressure: 80...110 kPa (0.8...1.1 bar) / 11.6...15.9 psi •...
  • Page 9 DEVICE DESCRIPTION OPTISWIRL 4200 The marking for equipment EPL Gb is: 1Ex db ia IIC T6...T2 Gb X 1Ex db ia IIC T6...T2 Gb X (compact version) 1Ex db ia IIC T6...T2 Gb X 1Ex db ia IIC T6...T2 Gb X 1Ex db e ia IIC T6...T2 Gb X...

  • Page 10: Ambient Temperature / Temperature Classes

    DEVICE DESCRIPTION OPTISWIRL 4200 2.6 Ambient temperature / temperature classes Because of the influence of the temperature of the product, no fixed temperature class is assigned to vortex flowmeters. The temperature class of these devices is rather a function of the product temperature and ambient temperature that is present and the specific device version.
  • Page 11 DEVICE DESCRIPTION OPTISWIRL 4200 The permitted ambient temperature range is indicated on the nameplate; depending on the device version it is T = -40...+65°C / -40...+149°F. The minimum product temperature is -40°C / -40°F. When using in zone 21, observe the maximum permissible product and ambient temperatures for temperature class 2 and the information for use of a heat-resistant connecting cable and cable entry.
  • Page 12 DEVICE DESCRIPTION OPTISWIRL 4200 Max. permissible product and ambient temperatures with signal converter or connection box mounted at side or underneath the flow sensor Figure 2-7: Signal converter at side of the flow sensor Temperature class in °C Nominal size DN15…25...
  • Page 13 DEVICE DESCRIPTION OPTISWIRL 4200 Max. permissible product and ambient temperatures for devices with painted flow sensors / signal converters or connection box mounted above the flow sensor Temperature class in °C Nominal size DN15…25 95 1 DN40…50 95 1 DN65…100...
  • Page 14 DEVICE DESCRIPTION OPTISWIRL 4200 Max. permissible product and ambient temperatures for devices with painted flow sensors / signal converters or connection box mounted at side or underneath the flow sensor Temperature class in °C Nominal size DN15…25 120 120 1...
  • Page 15 DEVICE DESCRIPTION OPTISWIRL 4200 Max. permissible product and ambient temperatures with signal converter in stainless steel (bright) or connection box in stainless steel (bright) mounted above the flow sensor Temperature class in °C Nominal size DN15…25 135 135 1 200 170 1 145 1 225 170 1 145 1 DN40…50...

  • Page 16: Surface Temperature For Equipment Protection Level Db

    DEVICE DESCRIPTION OPTISWIRL 4200 Max. permissible product and ambient temperatures with signal converter in stainless steel (bright) or connection box in stainless steel (bright) mounted at side or underneath the flow sensor Temperature class in °C Nominal size DN15…25 200 200...

  • Page 17: Electrical Data

    Binary output 8...32 VDC M1, M2, M3, M4 Current input 9...32 VDC 4...20 mA I1, I2 OPTISWIRL 4200 C FF Ex Bus connection 9...32 VDC 20 mA A1, A2 B1, B2 OPTISWIRL 4200 C PA Ex VFC 200 F PA 020 Ex 2 Table 2-14: Maximum values for signal circuits 1 Further information for operation of the FF transmitter are provided in separate supplementary instructions.

  • Page 18: Installation

    INSTALLATION OPTISWIRL 4200 3.1 Mounting Mounting and setup must be carried out according to the applicable installation standards (e.g. IEC 60079-14) by qualified personnel trained in explosion protection. The information given in the manual and these instructions must always be observed.

  • Page 19: Special Conditions

    INSTALLATION OPTISWIRL 4200 3.2 Special conditions Flameproof joints in the housing The housing must be replaced if there is any damage to the joint area. The flameproof thread gaps and the cylindrical joint between the terminal and the electronics compartments must be inspected visually after opening.

  • Page 20: Electrical Connections

    OPTISWIRL 4200 4.1 General notes Rated values for insulation • The insulation of the vortex flowmeter OPTISWIRL 4200 . .. - Ex is rated in compliance with IEC 60 664-1. The following rating parameters are taken into account: • Overvoltage category for signal and instrument loops: II •...
  • Page 21 ELECTRICAL CONNECTIONS OPTISWIRL 4200 Connecting cables The connecting cables should be selected according to the applicable installation standards (e.g. IEC 60079-14) and the maximum operating temperature. The connecting cable between the flow sensor and the wall bracket for remote versions is part of the supply.

  • Page 22: Power Supply

    ELECTRICAL CONNECTIONS OPTISWIRL 4200 4.2 Power supply The vortex flowmeter does not require a separate power supply. The required supply for the built-in electronics is provided via the 4...20 mA current output or the bus connection. 4.3 Inputs / Outputs The terminal assignment of the built-in electrical equipment is described in the standard documentation.

  • Page 23: Grounding And Equipotential Bonding

    ELECTRICAL CONNECTIONS OPTISWIRL 4200 4.4 Grounding and equipotential bonding CAUTION! Equipotential bonding Equipotential bonding Equipotential bonding Equipotential bonding Vortex signal converters and flow sensors must be included in the on-site equipotential bonding system according to the installation standard! They are connected to the PA terminals.
  • Page 24 ELECTRICAL CONNECTIONS OPTISWIRL 4200 For remote versions the connection of the flow sensor can either be made via the PA connection in the terminal compartment of the signal converter or via the external PA connection. Figure 4-2: Ground connection of the remote version...

  • Page 25: Flow Sensor Circuits (Remote Version Only)

    ELECTRICAL CONNECTIONS OPTISWIRL 4200 4.5 Flow sensor circuits (remote version only) Observe the following points when connecting the flow sensor to the signal converter: • Use only the supplied connecting cable (max. length 50 m / 164 ft). • Before connecting or loosening the equipotential bonding cable, ensure there are no differences in potential.

  • Page 26: Operation

    OPERATION OPTISWIRL 4200 5.1 Start-up Start-up is only permitted when the measuring device: • is correctly installed in the system and connected. • has been checked for the proper state with regard to its installation and connection requirements. • has been correctly locked to the electronics and terminal compartment.

  • Page 27: Electrostatic Charge

    OPERATION OPTISWIRL 4200 5.3 Electrostatic charge In order to avoid ignition hazards due to electrostatic charge, vortex flowmeters may not be used in areas with: • processes that generate strong charges, • mechanical friction and cutting processes, • spraying of electrons (e.g. in the vicinity of electrostatic painting systems) or •...

  • Page 28: Service

    SERVICE OPTISWIRL 4200 6.1 Maintenance Maintenance work of a safety-relevant nature within the meaning of explosion protection may only be carried out by the manufacturer, his authorised representative or under the supervision of authorised inspectors. ® Treat cover threads as necessary with the lubricating paint UNIMOLY C220 For systems in hazardous areas, regular tests are required in order to maintain the proper condition.
  • Page 29 SERVICE OPTISWIRL 4200 Take special note of the following figure and: • ensure that the type is the same by checking the nameplates. • the connecting cable of the flow sensor circuits is to be laid in the cutout provided between the converter insert and housing.

  • Page 30: Notes

    NOTES OPTISWIRL 4200 www.krohne.com 01/2019 - 4007443601 - AD OPTISWIRL4200 EAC Exd R01...
