Ltech EXIS Quick Start Manual

(Dimming)
EX1S F1
Ma ual n
www.ltech-led.com
Technical Specs
Dimming Touch Panel
EX1S
Input Voltage:
Output Signal:
Working Temp.:
F4-3A CV Receiver
Input Voltage:
Current Load:
Max Output Power:
Wireless Signal:
F4-5A CV Receiver
Input Voltage:
Current Load:
Max Output Power:
Wireless Signal:
F4-CC
CC Receiver
Input Voltage:
Receiver
Output Voltage:
Output Current:
Output Power:
Wireless Signal:
Note: Receiver is sold separately.
Dimensions:
100~240Vac
Package Size:
RF 2.4GHz, DMX512
Weight(G.W.):
-30℃~55℃
5~24Vdc Working Temp.:
3A × 4CH Max. 12A Dimensions:
60W/144W/288W(5V/12V/24V) Package Size:
2.4GHz Weight(G.W.):
5~24Vdc Working Temp.:
5A × 4CH Max. 20A Dimensions:
100W/240W/480W(5V/12V/24V) Package Size:
2.4GHz Weight(G.W.):
Working Temp.:
12~48Vdc
Dimensions:
3~46Vdc
Package Size:
CC 350/700/1050mA×4CH
Weight(G.W.):
1.05W~48.3W×4CH Max 193.2W
2.4GHz
L86×W86×H36(mm)
L113×W112×H50(mm)
225g
-30℃~55℃
L125×W33×H20(mm)
L127×W35×H24(mm)
60g
-30℃~55℃
L175×W44×H30(mm)
L178×W48×H33(mm)
150g
-30℃~55℃
L175×W44×H30(mm)
L178×W48×H33(mm)
165g
