Ltech DX4 Installation Instruction

1. Technical Specs:
DX4 RGBW Touch Panel
Input Voltage: 100~240Vac Dimensions:
Output Signal: RF 2.4GHz, DMX512 Package Size:
Working Temp.: -30℃~55℃ Weight(G.W.):
R4-5A CV Receiver
Input Voltage: 5~24Vdc Working Temp.:
Current Load: 5A × 4CH Max. 20A Dimensions:
Output Power: Max.100W/240W/480W(5V/12V/24V) Package Size:
Wireless Signal: 2.4GHz Weight(G.W.):
R4-CC
CC Receiver
Input Voltage:
12~48Vdc Working Temp.:
Output Voltage: Dimensions:
3~46Vdc
Output Current: Package Size:
CC 350/700/1050mA×4CH
Output Power: Weight(G.W.):
1.05W~48.3W×4CH Max 193.2W
Wireless Signal:
2.4GHz
Note: Receiver is sold separately.
2. Product Size:
Touch Panel R4-5A/R4-CC Receiver
1
DX4 RGBW Touch Panel
3. Installation Instruction:
L86×W86×H36(mm)
L113×W112×H50(mm)
225g
-30℃~55℃
L175×W44×H30(mm)
L178×W48×H33(mm)
150g
4. Key Functions:
-30℃~55℃
Speed/
Brightness-
L175×W44×H30(mm)
L178×W48×H33(mm)
On/Off
165g
Mode Key
Long press to turn on/off the tone.
The Changing Mode
1. Static Red 2. Static Green
6 . Static Cyan 7. Static White
11. 7 Colors Smooth
DX4 RGBW Touch Panel
Install Uninstall
5. Terminals:
Speed/
Brightness+
Touch Circle
White Key
Press to turn on/off
the white LEDs. 100-240Vac DMX Signal
Long press to change
Power Input Socket Output Socket
the brightness.
3. Static Blue 4. Static Yellow 5. Static Purple
8. RGB Jumping 9. 7 Colors Jumping 10 . RGB Smooth
12. Static Black (only turn off RGB)
2 www.ltech-led.com
