- Page 1 OPTIFLUX 2070 Quick Start Battery powered electromagnetic flowmeter...
-
Page 2: General Safety Notes
General safety notes You can find the newest and/or additional information on the CD-ROM provided, in the handbook, the datasheet, special manuals, certificates and the download center at www.krohne.com. Installation, mounting, commissioning, and maintenance can be performed only by trained personnel. -
Page 3: Visual Check
OPTIFLUX 2070 Visual check GK070: 10.234 Scope of delivery OPTIFLUX 2070 with blue protection cap Quick Start Factory calibration report CD-ROM including Handbook, Quick Start, Technical datasheet Grounding ring (optional) Cable (remote version only) www.krohne.com... - Page 4 OPTIFLUX 2070 Transport Inlet and outlet ≥ 5 DN ≥ 2 DN 7309992100...
-
Page 5: Mounting Position And Flange Deviation
OPTIFLUX 2070 Mounting position and flange deviation CAUTION! Max. permissible deviation of pipe flange faces: ≤ 0.5 mm www.krohne.com... - Page 6 OPTIFLUX 2070 Vibration Magnetic field 7309992100...
- Page 7 OPTIFLUX 2070 Bends Open discharge www.krohne.com...
-
Page 8: Control Valve
OPTIFLUX 2070 T-section ≥ 10 DN Control valve 7309992100... - Page 9 OPTIFLUX 2070 Pump Grounding Metal pipelines, not internally coated. Grounding without grounding rings! Metal pipelines with internal coating and non-conductive pipelines. Grounding with grounding rings! Grounding rings CAUTION! The grounding of the flowmeter provides a stable and accurate measurement. www.krohne.com...
-
Page 10: Torques And Pressures
OPTIFLUX 2070 Torques and pressures Nominal size Pressure Bolts Max. torque [Nm] DN [mm] rating Polypropylene Hardrubber PN 40 4 × M 16 PN 16 4 × M 16 PN 40 8 × M 16 PN 40 8 × M 16 PN 16 8 ×... - Page 11 OPTIFLUX 2070 Nominal size Flange class Bolts Max. torque [Nm] [inch] [lbs] Polypropylene Hardrubber 8 × 3/4" 12 × 7/8" 12 × 7/8" 12 × 1" 16 × 1" 16 × 1 1/8" 20 × 1 1/8" 20 × 1 1/4"...
- Page 12 OPTIFLUX 2070 Terminal assignment of IFC 070 7309992100...
-
Page 13: Electrical Values
OPTIFLUX 2070 Status output 1 Status output 2 Not connected Ground Pulse output A Pulse output B Electrical values f ≤ 500 Hz; I ≤ 10 mA; U: 5...24 VDC (P ≤ 100 mW) Pulse output passive: I ≤ 10 mA; U: 5...24 VDC (P ≤ 100 mW) Status output passive: www.krohne.com... - Page 14 OPTIFLUX 2070 Signal and field current cable for remote version CAUTION! Always use the supplied KROHNE signal cable. Cable connection for field version: flow sensor side cable length: 13 cm / 5" cable length: 5 cm / 2" cable length: 8 cm / 3"...
- Page 15 OPTIFLUX 2070 • Connect the shield to terminal 1, the purple cable to terminal 2 and the blue to terminal 3. Cable connection for field version: converter side cable length: 16 cm / 6.3" cable length: 5 cm / 2"...
- Page 16 OPTIFLUX 2070 • Connect the shield to terminal 1, the purple cable to terminal 2 and the blue to terminal 3. 7309992100...
-
Page 17: Connection Of Battery
OPTIFLUX 2070 Connection of battery CAUTION! Please connect the battery before first use. KROHNE delivers each IFC 070 converter with a disconnected battery. • remove the blue protection cap of the converter • remove the 4 Allen bolts (4 mm) •... -
Page 18: Display And Operating Elements
OPTIFLUX 2070 WARNING! Make sure that the battery cable is not jammed by the cover. • tighten the 4 Allen bolts • replace the blue protection cap Display and operating elements battery status optical key to navigate through the menu and to scroll through the measuring pages... - Page 19 OPTIFLUX 2070 Programming NOTE! KROHNE programs the signal converter according your wishes. It is ready to operate! The handbook on the CD contains more details. • Display test: press button 2x 1s • Software version: press button 1x 1s www.krohne.com...
- Page 20 OPTIFLUX 2070 Contact KROHNE Altometer KROHNE Altometer KROHNE Altometer KROHNE Altometer Kerkeplaat 12 3313 LC Dordrecht Postbus 110 3300 AC Dordrecht, the Netherlands www.krohne.com 7309992100...
