Z10
Kit dispensador Ø76
INSTRUCCIONES/
Quitar los tres tornillos de sujeción del
1
2
dispensador .
Remove the three screws that secure
the dispenser .
Desconectar el dispensador.
3
Disconnect the dispenser.
4
Desmontar la bandeja filtro Ref.1003025,
el soporte bandeja Ref. 1003026 y el filtro
exterior Ref. 1003027
Remove the filter tray Ref.1003025, tray
support Ref. 1003026 and the outer filter
Ref. 1003027
Posteriormente retirar la rejilla posava-
5
sos Ref.1002012A.
en remove the grille Ref.1002012A.
6
Quitar las bridas y abrazadera del hidro-
tubo Ø20 Ref.1011035.
Remove the flanges and clamps from the
hydrotube Ø20 Ref.1011035.
T +34 961 301 246 | F +34 961 301 250 | zummo@zummo.es | Cádiz, 4 . 46113 Moncada. Valencia. Spain | www.zummo.es
INSTRUCTIONS
1
3
5
2
4
6
