Zummo Z1 NATURE Maintenance Instructions

Hide thumbs Also See for Z1 NATURE:

MAINTENANCE INSTRUCTIONS

Z1 NATURE

Maintenance and

cleaning tips

We advise using protective gloves to handle our juicers.

Cleaning the juice extraction system and front cover at least once a day is advisable.

Do not forget to regularly check the peel containers.

It is not necessary to use specialized products.

All parts can be washed in the dishwasher (it is advisable to clean the front cover by hand).

The front covers of our juicers are

comprised of polycarbonate and ABS

models.For this reason, we advise not

cleaning them in the dishwasher to

prevent scratches or defects

Table of Contents

Need help?

Do you have a question about the Z1 NATURE and is the answer not in the manual?

Page 1 MAINTENANCE INSTRUCTIONS Z1 NATURE Maintenance and cleaning tips The front covers of our juicers are comprised of polycarbonate and ABS models.For this reason, we advise not cleaning them in the dishwasher to prevent scratches or defects We advise using protective gloves to handle our juicers.
Page 2 MAINTENANCE INSTRUCTIONS Z1 NATURE Clean the following components at least Clean weekly or twice a week when required: once a day: Juice extraction area: Feeder: Juice extraction tray Machine top Blade Peel extractor Filter tray and filter Front cover Container.
Page 3 DISASSEMBLY AND CLEANING INSTRUCTION Z1 NATURE With the machine stopped press Remove upper protection Extract the front cover. the off button. Be careful with blade. Remove container. Unscrew the nuts. Extract blade and cup. Unscrew the nut. Remove the juice...
Page 4 ASSEMBLY INSTRUCTIONS Z1 NATURE Fit the drip tray and grid. Mount the juice Mount the filter tray. extraction system. Screw the nut. Add the blade. Screw the nut. Add the cup. Screw the nut. Fit container. Fit upper protection. Insert the front cover into the grooves from right to left.
