- Page 1 RONI W - Room Air Conditioner RONI W R26W User R35W manual R50W R70W User manual...
-
Page 2: Table Of Contents
RONI W - Room Air Conditioner RONI W - ROOM AIR CONDITIONER User manual Contents SAFETY PRECAUTIONS..................................3 PART 1. NAMES OF PARTS ................................8 Indoor unit......................................8 Outdoor unit ......................................9 Indoor unit display ....................................9 PART 2. OPERATION INSTRUCTIONS .............................10 Manual device operation ................................10 Auto-restart function ..................................10 Emergency function ..................................10 Operating temperature .................................11... - Page 3 RONI W - Room Air Conditioner PRECAUTIONS WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
-
Page 4: Safety Precautions
RONI W - Room Air Conditioner SAFETY PRECAUTIONS 1. INTRODUCTION TO REFRIGERANTS R32 The refrigerants used for air conditioners are environmentally friendly hydrocarbons R32. The two kinds of refrigerants are combustible and odorless. Moreover, they can bum and explode under certain condition. How- ever, there will be no risk of buming and explosion if you comply with the following table to install your air conditioner in a room with an appropriate area and use it correctly. - Page 5 RONI W - Room Air Conditioner SAFETY PRECAUTIONS 3. SAFETY RULES AND RECOMMENDATIONS FOR THE INSTALLER CAUTIONS • Read this guide before installing and using the • The appliance must be fitted with means for appliance. disconnection from the supply mains having a contact separation in all poles that pro vide •...
- Page 6 RONI W - Room Air Conditioner SAFETY PRECAUTIONS CAUTIONS • This appliance can be used by children a ged • Always use the appliance with the air filter from 8 years and above and persons with mounted . The use of the conditioner without reduced physical, sensory or mental capabilities air filter could cause an excessive accumulation or lack of experience and kn owledge if they...
- Page 7 RONI W - Room Air Conditioner SAFETY PRECAUTIONS 4. SAFETY RULES AND PROHIBITIONS CAUTIONS • In no way alter the characteristics of the appli- • Do not install the appliance in environments ance. where the air could contain gas , oil or sulphur or near sources of heat.
-
Page 8: Part 1. Names Of Parts
RONI W - Room Air Conditioner PART 1. NAMES OF PARTS 1. INDOOR UNIT Rys. 1 Fig. 2 1. Front panel 7. Ionizer generator (if installed) 2. Air filter 8. Deflectors 3. Optional filter (if installed) 9. Emergency button 4. LED Display 10. -
Page 9: Indoor Unit Display
RONI W - Room Air Conditioner PART 1. NAMES OF PARTS 3. INDOOR UNIT DISPLAY SLEEP SLEEP mode DISPLAY 1. Lights up during Timer operation when the air conditioner is operational 2. Displays the malfunction code when fault occurs. Fig. 4 TIMER Zapala się... -
Page 10: Part 2. Operation Instructions
RONI W - Room Air Conditioner PART 2. OPERATION INSTRUCTIONS 1. MANUAL DEVICE OPERATION Indoor units are equipped with a button to control the device during crash remote . You can get to it by opening the front panel. Use the button only when there is a failure or the need for a wireless remote con- trol service. -
Page 11: Operating Temperature
RONI W - Room Air Conditioner PART 2. OPERATION INSTRUCTIONS 4. OPERATING TEMPERATURE Mode Cooling operating Heating operating Temperature Room temperature 17°C~32°C 0°C~30°C Outdoor temperature -15°C~53°C -20°C~30°C NOTE The unit does not operate immediately if it is turned on after being turned off or after changing the mode during operation. -
Page 12: Part 3. Cleaning And Maintenance
RONI W - Room Air Conditioner PART 3. CLEANING AND MAINTENANCE Periodic maintenance is essential for keeping your air conditioner efficient. Before carrying out any maintenance, disconnect the power supply by taking the plug out from the socket. 1. INDOOR UNIT CLEANING Anti dust filter 1. -
Page 13: Part 4. Remote Controller
RONI W - Room Air Conditioner PART 4. REMOTE CONTROLLER 1. REMOTE CONTROLLER BUTTONS Pic. 9 Button Function To turn on or off the air conditioner. OPTION To activate or deactivate optional function (Check below table). To decrease temperature, time setting or choose the function. To increase temperature , time setting or choose the function. -
Page 14: Remote Controller Display
RONI W - Room Air Conditioner PART 4. REMOTE CONTROLLER ON/OFF Mode Function AUTO CLEAN, TIMER, DISPLAY, HEALTH, I FEEL, 8°CH COOL CLEAN, TIMER, DISPLAY, HEALTH, SLEEP, MILDEW, I FEEL, 8°CH CLEAN, TIMER, DISPLAY, HEALTH, MILDEW, I FEEL, 8°CH CLEAN, TIMER, DISPLAY, HEALTH, I FEEL, 8°CH HEAT CLEAN, TIMER, DISPLAY, HEALTH, SLEEP, I FEEL, 8°CH CAUTION... -
Page 15: Replacement Of Batteries
RONI W - Room Air Conditioner PART 4. REMOTE CONTROLLER Symbols Meaning Optional functions indicator CAUTION You will hear a beep when you press the following buttons or select the following optional functions, though the actual model haven't this function, we express our apologies: HEALTH (Optional Function: generate the ionizer) (Button: SWING LEFT/RIGHT) [8°CH] (Optional Function: 8°C Heating) - Page 16 RONI W - Room Air Conditioner PART 4. REMOTE CONTROLLER • When you insert the batteries for the first time in the remote controller or if you change them, you can program the temperature display switchover function between °C and °F. 1.
-
Page 17: Part 5. Operating Instructions
RONI W - Room Air Conditioner PART 5. OPERATING INSTRUCTIONS Filter The air sucked by the fan enters from the grill and passes through the filter, then it is cooled/dehumidified or heat- ed through the heat exchanger. The direction of the air outlet is motorized up and down by flaps, and manually moved right and left by the ver- tical deflectors, for some models, the vertical deflectors Heat... -
Page 18: Cooling Mode
RONI W - Room Air Conditioner PART 5. OPERATING INSTRUCTIONS 2. COOLING MODE The cooling function allows the air conditioner to cool the room and at the same time reduces Air humidity. To activate the cooling function (COOL), press the MODE button until the symbol COOL appears on the display. -
Page 19: Dry Mode
RONI W - Room Air Conditioner PART 5. OPERATING INSTRUCTIONS 5. TIMER FUNCTION To set the automatic switch-on /off of the air conditioner. Timer setting/change/cancel: 1. Press OPTION at the first time, select the TIMER by pressing the button or until symbol TIMER is flashing; 2. -
Page 20: Auto Mode
RONI W - Room Air Conditioner PART 5. OPERATING INSTRUCTIONS 7. AUTO MODE To activate the AUTO (automatic) mode of operation, press MODE button on the remote controller until the symbol AUTO appears on the display. In AUTO mode the fan speed and the temperature are set automatically according to the room temperature (tested by the temperature sensor which is incorporated in the indoor unit). - Page 21 RONI W - Room Air Conditioner PART 5. OPERATING INSTRUCTIONS 10. DISPLAY FUNCTION (INDOOR DISPLAY) Switch on/off the LED display on panel Press OPTION at the first time , select the DISPLAY by press- ing the button or until symbol DISPLAY is flashing; Press OPTION again to switch off the LED display on the pan- el, and DISPLAY appears on the remote controller display.
-
Page 22: Self-Clean Function (Optional)
RONI W - Room Air Conditioner PART 5. OPERATING INSTRUCTIONS 13. SELF-CLEAN FUNCTION Press OPTION at the first time, select the CLEAN by press- ing the button or until symbol CLEAN is flashing; Press OPTION again to activate the CLEAN function, and appears on the display. - Page 23 RONI W - Room Air Conditioner PART 5. OPERATING INSTRUCTIONS 15. HEATING FUNCTION (OPTIONAL) It can be set in COOL/HEAT/DRY/FAN/AUTO mode, but you need to turn off the unit to activate it. Press OPTION at the first time, select the 8°CH by pressing the button or until symbol 8°CH is flashing;...
-
Page 24: Part 6. Troubleshooting
RONI W - Room Air Conditioner PART 6. TROUBLESHOOTING 1. MALFUNCTIONS Malfunction Possible causes Power failure/plug pilled out Damaged indoor/outdoor unit fan motor Faulty compressor thermomagnetic circuit breaker Faulty protective device or fuses The appliance does not Loose connections or plug pulled out operate It sometimes stops operating to protect the appliance Voltage higher or lower than the voltage range... -
Page 25: Error Signals On The Display
RONI W - Room Air Conditioner PART 6. TROUBLESHOOTING CAUTION Switch off the air conditioner immediately and cut off the power supply in the event of: • Strange noises during operation • Faulty electronic control board • Faulty fuses or switches •... - Page 26 RONI W - Room Air Conditioner NOTES ......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................User manual...
- Page 27 RONI W - Room Air Conditioner NOTES ......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................User manual...
- Page 28 RONI W - Room Air Conditioner www.rotenso.com email: info@rotenso.com Installer stamp User manual...
