- Page 1 RONI W Roni R26W User Roni R35W manual Roni R50W...
-
Page 2: Table Of Contents
RONI W - Room Air Conditioner RONI W - ROOM AIR CONDITIONER User manual Contents SAFETY PRECAUTIONS....................................3 PART 1. NAMES OF PARTS ..................................8 Indoor unit ........................................... 8 Outdoor unit ........................................9 Indoor unit display ......................................9 PART 2. OPERATION INSTRUCTIONS ..............................10 Manual device operation....................................10 Auto-restart function .....................................10 Emergency function .......................................10... -
Page 3: Safety Precautions
RONI W - Room Air Conditioner SAFETY PRECAUTIONS WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury. - Page 4 RONI W - Room Air Conditioner SAFETY PRECAUTIONS 1. INTRODUCTION TO REFRIGERANTS R32 The refrigerants used for air conditioners are environmentally friendly hydrocarbons R32. The two kinds of refrigerants are combustible and odorless. Moreover, they can bum and explode under certain condition. However, there will be no risk of buming and explosion if you comply with the following table to install your air conditioner in a room with an appropriate area and use it correctly.
- Page 5 RONI W - Room Air Conditioner SAFETY PRECAUTIONS 3. SAFETY RULES AND RECOMMENDATIONS FOR THE INSTALLER CAUTIONS • Read this guide before installing and using the • The appliance must be fitted with means for appliance. disconnection from the supply mains having a contact separation in all poles that pro vide full •...
- Page 6 RONI W - Room Air Conditioner SAFETY PRECAUTIONS CAUTIONS • This appliance can be used by children a ged from • Always use the appliance with the air filter 8 years and above and persons with reduced mounted . The use of the conditioner without air physical, sensory or mental capabilities or lack filter could cause an excessive accumulation of of experience and kn owledge if they have been...
- Page 7 RONI W - Room Air Conditioner SAFETY PRECAUTIONS 4. SAFETY RULES AND PROHIBITIONS CAUTIONS • In no way alter the characteristics of the appli ance. • Do not install the appliance in environments where the air could contain gas , oil or sulphur or •...
-
Page 8: Part 1. Names Of Parts
RONI W - Room Air Conditioner PART 1. NAMES OF PARTS 1. INDOOR UNIT Fig. 1 Fig. 2 1. Front panel 7. Ionizer generator (if installed) 2. Air filter 8. Deflectors 3. Optional filter (if installed) 9. Emergency button 4. LED Display 10. -
Page 9: Indoor Unit Display
RONI W - Room Air Conditioner PART 1. NAMES OF PARTS 3. INDOOR UNIT DISPLAY SLEEP SLEEP mode DISPLAY 1. Lights up during Timer operation when the air conditioner is operational 2. Displays the malfunction code when fault occurs. Fig. 4 TIMER Lights up during Timer operation. -
Page 10: Part 2. Operation Instructions
RONI W - Room Air Conditioner PART 2. OPERATION INSTRUCTIONS 1. MANUAL DEVICE OPERATION Indoor units are equipped with a button to control the device during crash remote . You can get to it by opening the front panel. Use the button only when there is a failure or the need for a wireless remote control service. 2. -
Page 11: Operating Temperature
RONI W - Room Air Conditioner PART 2. OPERATION INSTRUCTIONS 4. OPERATING TEMPERATURE Mode Cooling operating Heating operating Temperature Room temperature 17°C~32°C 0°C~30°C Outdoor temperature -15°C~53°C -20°C~30°C NOTE The unit does not operate immediately if it is turned on after being turned off or after changing the mode during operation. -
Page 12: Part 3. Cleaning And Maintenance
RONI W - Room Air Conditioner PART 3. CLEANING AND MAINTENANCE Periodic maintenance is essential for keeping your air conditioner efficient. Before carrying out any maintenance, disconnect the power supply by taking the plug out from the socket. 1. INDOOR UNIT CLEANING Anti dust filter 1. -
Page 13: Part 4. Remote Controller
RONI W - Room Air Conditioner PART 4. REMOTE CONTROLLER 1. REMOTE CONTROLLER BUTTONS Fig. 9 Button Function (TEMP UP) Press it to increase temperature / time setting. (TEMP DN) Press it to decrease temperature/ time setting. ON/OFF Press it to start or stop operation. To select the fan speed of auto/low/mid/high . -
Page 14: Remote Controller Display
RONI W - Room Air Conditioner PART 4. REMOTE CONTROLLER Button Function To switch active /deactive "I FEEL" function.The air conditioner will regulate the room temperature based I FEEL on the temperature(0 ~50 ) around the remote controller.This function will terminate 2 hours later once it's active. -
Page 15: Replacement Of Batteries
RONI W - Room Air Conditioner PART 4. REMOTE CONTROLLER Symbol Function AUTO FAN indicator LOW FAN SPEED indicator MIDDLE FAN SPEED indicator HIGH FAN SPEED indicator SLEEP indicator FLAP SWING (HORIZONTAL) indicator FLAP SWING (VERTICAL) indicator SUPER indicator HEALTHY indicator ECO indicator BATTERY indicator CLOCK and TEMPERATURE indicator... - Page 16 RONI W - Room Air Conditioner PART 4. REMOTE CONTROLLER NOTE After adjusting the function, you need to take out the batteries and repeat the procedure described above. • When you insert the batteries for the first time in the remote controller or if you change them, you need to program the remote controller of only cooling or cooling and heating.
-
Page 17: Part 5. Operating Instructions
RONI W - Room Air Conditioner PART 5. OPERATING INSTRUCTIONS The air sucked by the fan enters from the grill and passes through the filter, then it is cooled/dehumidified or heated Filter through the heat exchanger. The direction of the air outlet is motorized up and down by flaps, and manually moved right and left by the vertical deflectors, for some models, the vertical deflectors could be controlled by motor as well. -
Page 18: Cooling Mode
RONI W - Room Air Conditioner PART 5. OPERATING INSTRUCTIONS 2. COOLING MODE The cooling function allows the air conditioner to cool the room and at the same time reduces Air humidity. To activate the cooling function (COOL), press the (MODE) button until the symbol (COOL) appears on the display. -
Page 19: Timer Mode
RONI W - Room Air Conditioner PART 5. OPERATING INSTRUCTIONS 4. TIMER MODE • TIMER ON To program the automatical switching-on the appliance should be power OFF. Press (TIMER) button at the fist time, set the temperature with pressing the button Press (TIMER) at the second time, set the rest time with Fig. -
Page 20: Fan Mode
RONI W - Room Air Conditioner PART 5. OPERATING INSTRUCTIONS 5. FAN MODE To set the FAN mode Press (MODE) untill (FAN) appears in the display. Whitch pressing (FAN) button the speed changes in the following sequence: LOW/ MEDIUM / HIGH /AUTO in FAN mode. The remote control also stores speed that was set in the previous mode of operation. -
Page 21: Sleep Mode
RONI W - Room Air Conditioner PART 5. OPERATING INSTRUCTIONS 8. SLEEP MODE To activate the SLEEP mode of operation, press the (SLEEP) button on the remote controller until the symbol (AUTO QUIET) appears on the display The function SLEEP" automatically adjusts the temperature to make the room more comfortable during the night. -
Page 22: Part 6. Troubleshooting
RONI W - Room Air Conditioner PART 6. TROUBLESHOOTING 1. MALFUNCTIONS Malfunction Possible causes Power failure/plug pilled out Damaged indoor/outdoor unit fan motor Faulty compressor thermomagnetic circuit breaker Faulty protective device or fuses The appliance does not Loose connections or plug pulled out operate It sometimes stops operating to protect the appliance Voltage higher or lower than the voltage range... -
Page 23: Error Signals On The Display
RONI W - Room Air Conditioner PART 6. TROUBLESHOOTING CAUTION Switch off the air conditioner immediately and cut off the power supply in the event of: • Strange noises during operation • Faulty electronic control board • Faulty fuses or switches •... - Page 24 Installer stamp...
