Summary of Contents for Jolly X-Beam 440
- Page 1 USER MANUAL...
-
Page 3: Table Of Contents
Table of content 1.Open-Package guidelines............... １.１Package....................1 2.Safety instructions..................1 .... 3.Operating determination.............3 4.Rigging the fixture...................4 4.1 Mounting.....................4 4.2Installing the Clamps................4 4.3 Power supply connection and cut off...........5 4.4 Power Connection................6 4.5 DMX-512 connection/connection between fixtures......6 Description of the device............ - Page 4 Congratulations on choosing our products! Please carefully read this instruction manual in its entirety and keep it well for using reference. This manual contained about the installation and the relative using information of this products. Plese refere this manual's relative instruction when using this equipment.
-
Page 5: Open-Package Guidelines
1.Open-Package guidelines This equipment is made of new style,high intensity plastic.It fully shows the modem times light charac teris- tic with teristic with beauty struture. And it is made accord to CE standard. Fully agree with the internation standard of DMX 512 agreement. - Page 6 Never let the power-cord come into contact with other cables! Handle the power cord and all connections with particular caution! Make sure that the available voltage is not higher than stated on the rearpanel. Always plug in the power plug least. Make suer that the power-switch is set to off-position before you con ections with themains with particular caution! Make sure that the power-cord is never crimped or damaged by sharp edges.Check the decice and the p- ower-cord from time to time.
-
Page 7: Operating Determination
lines of the projectors from indirect contact and/orshorting to earth by using appropriately sized residual current devices. Disposing This product is supplied in compliance with European Directive 2012/19/EU-Waste Electrical and Electronic Equipment (WEEE). To preserve the environment please dispose/recycde this product at the end of its life according to the local regulation. -
Page 8: Rigging The Fixture
4.Rigging the fixture 4.1 Mounting Pay attention to the regulations of CE. Installation by qualified staff to complete. For the various mounting positions of the FIXTURE(standing on the floor, sideways or hanging different accessories kits are available. Through this a safe and firm installation is assured. You’ll find special connectors on the bottom side of the system which are put to use here. -
Page 9: Power Supply Connection And Cut Off
The projector can be placed directly on the stage floor or rigged in any orientation on atruss without alte- ring its operation characteristics. For overhead use,always install a safety-rope that can hold at least 10 times the weight of the fixture.You must only use safety-ropes with screw on carabines.Pull the safety-rope through the two apertures on the bottom of the base and over the trussing system etc. -
Page 10: Power Connection
4.4 Power Connection If you wish to change the power supply settings, see the chapter appendix Connect the fixture to the mains with the enclosed power cable and plug. Warning: please verify the power of the power supply equipment prior to the connection! Earth wire must be grounded! CABLE(EU) CABLE(US) -
Page 11: Description Of The Device
DMX Terminator Diagram -For installations where the DMX cable has to run a long distance or is In an electrically noisy environment it is recommended to use a DMX terminator. This help in preventing corruption of the signal by electrical noise. The DMX terminato r is simply an XLR plug witha Ω... -
Page 12: Dimension
6.Dimension - 8 -... -
Page 13: Display Control
7.Display control 7.1 Navigation in the Menu Using the buttons or touch screen, and this can be simply and easily set the address code and functions code. If you view or modify the lighting feature set, then press ENTER button, the display will enter the menu interface. - Page 14 Click on the main interface of the icon, numerical to view view Settings related information of lamps and lanterns.Symbols such as the main interface appear “ “,the following error message indicates that there might be a lamps and lanterns,can click to view and control information content to modify the lamps and lanterns.
-
Page 15: Menu Maps
7.3 Unit Menu Remark Dmx Address 001~XXX Dmx Address Mode1 1~22 Channel Mode default Mode1 Mode2 1~22 Mode3 1~16 Set up Fixture Id 0001~9999 Lamps address IP Address Network Setup Art-Net Set up Net Mask Universe Fixture Times XXXXX h XX m Total working hours Lamp On Times XXXXh XXm Lamp On working hours... -
Page 16: Dmx Protocol
8.DMX protocol Mode1 Mode2 Mode3 Fade Type Function Value 0-255 Pan Fime Pan Fime 0-255 Tilt Tilt 0-255 Tilt Fime Tilt Fime 0-255 Continual positioning Empty position Empty → colour 1 4-12 colour 1 → colour 2 13-21 colour 2 → colour 3 22-30 colour 3 →... - Page 17 Mode1 Mode2 Mode3 Fade Type Function Value Gobo 9 56-59 Gobo Shakes at variable speed from slow to fast. Gobo 1 60-67 Gobo 2 68-75 Gobo 3 76-83 Gobo 4 84-91 Gobo 5 92-99 Gobo 6 100-107 Gobo 7 108-115 Gobo 8 116-123 Gobo 9...
- Page 18 Mode1 Mode2 Mode3 Fade Type Function Value Gobo 18 69-71 Continuous gobo rotation at linearly variable 72-113 speed from fast to slow Stop rotation 114-117 Continuous gobo rotation at linearly variable 118-159 speed from slow to fast Shaking gobos from slow to fast Gobo 1 160-165 Gobo 2...
- Page 19 Mode1 Mode2 Mode3 Fade Type Function Value Effects Reset -5 sec 63-75 Pan/Tilt Reset 76-87 Total reset 88-101 Function Lamp Off -5 sec 102-114 Lamp On -5 sec 115-234 Unused Range 235-255 Pan-Tilt time Pan-Fine Pan-Tilt-Tilt Fine 0-255 Colour time Cyan - Magenta - Yellow 0-255 Gobo time Static Gobo-Rotating Gobo...
-
Page 20: Maintance And Cleaning
9.Maintance and cleaning DANGER:Disconnect from the mains before starting any maintenance work. It is absolutely essential that the fixture is kept clean and that dust,dirt and smoke fluid residues must not buildup on or within the fixture. Otherwise, the fixtures light-output will be significantly reduced. Regular cleaning will not only ensure the maximum light-output, but will also allow the fixture to function reliably through out its life. -
Page 21: Light Table
2．Each DMX Value displayable. 3．Time of automatic turning off is able to set on the display. 4．Display the time using of lighting feature and lamp as well as the times of turning on for lamp. 5．With function of turn on lamp when powered. Automatic 50 % energy saving of power when turn off the strobe. -
Page 22: Gobo Wheel
Gobo wheel 10.6 Fix gobo wheel Integra，Inside diameterφ118mm,effective diameter 9mm. Rgobo wheel Glass design Inside diameterφ15.9mm,effective diameter 7mm. - 18 -... -
Page 23: Color Wheel
9.7 Color wh eel Deep fluorescence Brown yellow Dark red Green Red Brown Dark blue Light blue film Magnets Light red Orange Pink Yellow - 19 -... -
Page 24: Electronic Drawing
11.Electronic drawing Titl EN Pan EN Lamp Lamp Blower Blower 90 Fan 90 Fan Titl Sensor Fan1 Fan2 Cable Lable (F1) (F2) (F3) (F4) Pan Sensor FAN1 FAN2 FAN3 FAN4 Titl Motor Motor Lamp Lamp Power Supply 48V Fan Driver Board Gobo Power Supply Battery... - Page 26 ht tp: //www.jol lyl ight ing. com Guangzhou hongcai stage equipment Co.,Ltd Tel:+862084558833 Fax:+862084559699 Email:info@jollylighting.com P.C:511450 Add:Building2,No.32,Changsha Street,Shachong Village,shiji Tow.Panyu District,Guangzhou,China...
