Problem
Poor Grass Discharge
For all other maintenance and operation issues, please contact your authorized dealer.

Specifications

Deck Size (in / cm)
Height of Cut (in / cm)
Transmission Type
Ground Speed - Forward (mph / kph)
Ground Speed - Reverse (mph / kph)
Engine Displacement * (cc)
Spark Plug Gap (in / mm)
Spark Plug Torque (lb-in / Nm)
Oil Capacity (oz / l)
Fuel Tank Capacity (qt / l)
Tire Pressure - Front (psi / bar)
Tire Pressure - Rear (psi / bar)
*Power Ratings: The gross power rating for individual
gasoline engine models is labeled in accordance with SAE
(Society of Automotive Engineers) code J1940 Small Engine
Power & Torque Rating Procedure, and is rated in accor-
dance with SAE J1995. Torque values are derived at 2600
RPM for those engines with "rpm" called out on the label and
3060 RPM for all others; horsepower values are derived at
3600 RPM. The gross power curves can be viewed at www.
BRIGGSandSTRATTON.COM. Net power values are taken
with exhaust and air cleaner installed whereas gross power
values are collected without these attachments. Actual gross
engine power will be higher than net engine power and is
affected by, among other things, ambient operating condi-
tions and engine-to-engine variability. Given the wide array of
products on which engines are placed, the gasoline engine
may not develop the rated gross power when used in a
given piece of power equipment. This difference is due to a
variety of factors including, but not limited to, the variety of
engine components (air cleaner, exhaust, charging, cooling,
carburetor, fuel pump, etc.), application limitations, ambient
operating conditions (temperature, humidity, altitude), and
engine-to-engine variability. Due to manufacturing and capac-
ity limitations, Briggs& Stratton may substitute an engine of
higher rated power for this engine.
24
Probable Cause
1. Engine speed too slow.
2. Forward ground speed too fast.
3. Grass is wet.
4. Build up of grass clippings and
debris under deck.
Corrective Action
1. Move engine speed control to FAST
position.
2. Adjust unit to a slower ground speed.
3. Mow when grass is dry.
4. Clean the underside of deck.
2691347-00 2691348-00 /
2691354-00
33 / 84 33 / 84
1.5 - 4.0 / 3,8 - 10,2 1.5 - 4.0 / 3,8 - 10,2
5-speed disc drive Hydro
1.0 - 4.5 / 1,6 - 7,2 0 - 4.25 / 0 - 6,84
0 - 1.9 / 0 - 3,1 0 - 1.7 / 0 - 2,8
344 500
0.030 / 0,76 0.030 / 0,76
180 / 20 180 / 20
48 / 1,40 48 / 1,40
8 / 7,6 8 / 7,6
15 / 1,03 15 / 1,03
12 / 0,83 12 / 0,83
