- Page 1 Parts Manual for 21" OPENING PRICE POINT WALK BEHIND MOWER SERIES 0 MODEL RO21380 McDonough, GA, 30253 U.S.A. COPYRIGHT © 2005 Manual No. 7006048 SNAPPER PRODUCTS, INC. Revision 1, 10/11/2005 TP 400-5123-1-WB-N ALL RIGHTS RESERVED.
-
Page 3: Table Of Contents
PAGE GROUP Handles & Controls Cutting Deck, Blade, Interlock Wheels, Guards, Axles Side Chute, Adapter Decals 21" OPENING PRICE POINT SERIES 0 Table Of Contents Manual No. 7006048 TP 400-5123-1-WB-N... -
Page 4: Handles & Controls
Handles & Controls Manual No. 7006048 21" OPENING PRICE POINT TP 400-5123-1-WB-N SERIES 0... - Page 5 Handles & Controls Item Part No Description 7074384 HANDLE, Upper 7033406 HANDLE, Middle 7091022 SCREW, 1/4-28 x 1-3/4" Hex Head Cap 7090053 WASHER, 1/4 Internal Tooth Lock 7017072 CONTROL, Blade 7033904 CLIP, Blade Control 7016707 CABLE, Blade Control 7014343 BUSHING 7023813 CLIP, Wiring Harness 7026141...
-
Page 6: Cutting Deck, Blade, Interlock
Cutting Deck, Blade, Interlock Manual No. 7006048 21" OPENING PRICE POINT TP 400-5123-1-WB-N SERIES 0... - Page 7 Cutting Deck, Blade, Interlock Item Part No Description 7053271 DECK, Mower 7017168 BLADE, Cutter 7090167 SCREW, 3/8-24 x 2" Hex Head Cap (Gr. 5) 7012063 WASHER, Cone 7010783 KEY, Hi-Pro 7012927 HUB, Blade Drive 7033408 SPRING, Interlock 7012048 INSULATOR, Interlock 7090385 WASHER, #8 Tab 7090379...
-
Page 8: Wheels, Guards, Axles
Wheels, Guards, Axles Manual No. 7006048 21" OPENING PRICE POINT TP 400-5123-1-WB-N SERIES 0... - Page 9 Wheels, Guards, Axles Item Part No Description 7022374 WHEEL, Front & Rear 8 x 2.00 7026667 GUARD, Rear Foot 7026643 SUPPORT, Foot Guard 7090913 SCREW, #10-24 x 1/2" Hex Washer Self-Tap (Torx) 7091221 BOLT, 3/8-16 x 2-7/16" Shoulder 7011121 WASHER, 5/8 Belleville 7091220 WASHER, 9/16 x 1-1/16"...
-
Page 10: Side Chute, Adapter
Side Chute, Adapter Manual No. 7006048 21" OPENING PRICE POINT TP 400-5123-1-WB-N SERIES 0... - Page 11 Side Chute, Adapter Item Part No Description 7026560 COVER, Recycling 7091508 BOLT, 5/16-18 x 3/4" Short Neck Carriage 7091303 BOLT, 5/16-18 x 1" Short Neck Carriage 7090951 NUT, 5/16-18 Center Lock 7011791 RETAINER, 5/16 Bolt 7091076 WASHER, 5/16 Flat 7024340 SPACER Footnotes: 21"...
-
Page 12: Decals
Decals Manual No. 7006048 21" OPENING PRICE POINT TP 400-5123-1-WB-N SERIES 0... - Page 13 Decals Item Part No Description 7026388 LOGO, SNAPPER (Recycling / Mulching) 7024211 DECAL, Blade Control 7013010 DECAL, Danger Footnotes: 21" OPENING PRICE POINT SERIES 0 Note Manual No. 7006048 TP 400-5123-1-WB-N...
- Page 16 21" OPENING PRICE POINT WALK BEHIND MOWER SERIES 0 IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
