PGA-710 Autoanalysis System
How To Measure Guide
For PGA-710 Autoanalysis System Only
Currently only available in English & Japanese
Last updated: January 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PGA-710 and is the answer not in the manual?

Questions and answers

Related Manuals for Prostat PGA-710

Summary of Contents for Prostat PGA-710

  • Page 1 PGA-710 Autoanalysis System How To Measure Guide For PGA-710 Autoanalysis System Only Currently only available in English & Japanese Last updated: January 2011...
  • Page 2 CVM-780 Contact Voltmeter Set Quick Start Guide Copyright  2001-2011 by PROSTAT Corporation. All rights reserved. Printed in the United States of America. No part of this manual may be used or reproduced in any manner whatsoever without written permission. For information contact PROSTAT Corporation, 1072 Tower Lane, Bensenville, IL 60106 PROSTAT is the registered trademark of PROSTAT...

  • Page 3: Table Of Contents

    VII. Offset Voltage & Decay Time Measurement Procedures ..........25 VIII. Understanding Ionization & Measurement Objectives ........... 27 Analyzing Decay Time Data & Generating Reports ............29 Assembled Decay Charts ....................32 PGA-710 Autoanalysis System – How To Measure Guide...

  • Page 4: General

    In effect, using the following procedure with the PGA-710 Autoanalysis system calculates and reports the probability of personnel equaling, or exceeding levels of body voltage under specific conditions.

  • Page 5: Instrument Setup For Body Voltage

    PFM-711A Field Meter equipped with the CPM-720 Charge Plate Monitor accessory. However, other devices having specified tolerances and output voltages ±2 volts or less may be used with the PROSTAT PGA-710 Autoanalysis System. Confirm that the measurement instrument’s maximum output voltage does not exceed 2.0 volts and that connections are compatible before using other instruments with the PGA-710.
  • Page 6 4. Connect the instruments. Plug one end of the analog output cable into the PFM-711A Field Meter, and the other end into the PGA-710 Autoanalyzer. See Figure 3, below. Figure 3: Connect Field Meter Output to Autoanalyzer input 5.
  • Page 7 Figure 6: Enter number of Step Cycles Figure 7: Enter Personnel & Material Information 11. Enter address and test area information and click Finish to complete Session Wizard. Figure 8: Test Location Information PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 8 13. Select background, line colors and temperature type ( F or both). Change colors or include reference lines using the Document drop down, Appearance Options menu. Figure 10: Appearance Window Changes Backgroundand Selected Display Elements PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 9 If using a black background a Lime Green trace will appear in the screen window at approximately zero Figure 12: Previewing the zero reference d. Press the Black Square ■ or F8 to stop the preview PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 10 Figure 14: Press Voltage Auto Balance button of F11 to display all data in the screen view b. If the zero reference is greater than 0 ± 2 Volts, zero the System as follows: PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 11 Remove the shorting shunt and reinstall the PFM-711A analog output cable INFORMATION NOTE The PGA-710 Autoanalysis System is a precision instrument. Depending on the environment and while rare, the System’s zero reference may be affected by high levels of extraneous transmitted energy, or “noise” i.e., EMI/RFI. All units are easily zeroed as described above unless influenced by excessive noise.

  • Page 12: Measure Body Voltage Generation

    The following demonstrates high voltage generation. Press the Voltage Auto Balance button (F11) to bring the entire trace within the display view. PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 13 Figure 19: To fit all data on the display horizontally press Time Scale Auto Fit Button (F12) c. Notice that the Test Information section displays the Type of test and its status PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 14 Trimmed Area Removed from Analysis & Calculations Figure 21: Trimmed data is not used for the analysis, but is not eliminated from the data file. Use Undo Trim to remove Trim Areas PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 15 Adjust function in the Edit Control window. Use the Add or Remove buttons to include or eliminate various peaks from the analysis. Figure 25: Edit Control Window PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 16 3 Sigma range (Average plus and minus 3 times the standard deviation) for Standing body voltage range c. The Average for each Walking and Standing body voltage ranges PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 17 If the Body Voltage Test is selected, a full size 8.5 x 11.0 inch landscape chart will be generated for printing, or export (Figure 29). Any information entered in the Session Wizard will be included on the chart. PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 18 Selecting the Body Voltage Analysis (Abs) report will generate graphs where their slopes will be calculated using absolute values of the data. (Figure 30) Figure 30: Full Size Chart with Session Wizard Information PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 19 Descriptive Information that was input to the Session Wizard General Calculations and Footer Information, which includes File Name, Time and Date document was printed, and page numbers Figure 32: First Page of Body PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 20 Exceeding a given Peak Body Voltage of Personnel while Walking -- Based on Average Maximum Peaks ± 3 Standard Figure 34: Third Page of Body Voltage Generation Deviations Report – Probability of Equaling or Exceeding a defined Voltage PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 21 ESD footwear and stepping onto a floor surface. The PGA-710 Autoanalysis System was originally designed primarily for ionization decay analysis. However, other decay analysis applications are apparent. The following illustrations focus on measuring decay time of a bench top ionizer. The principles apply to many other evaluations and measurements where the voltage change over time is an important measurement.

  • Page 22: Instrument Test Setup For Decay

    1. Mount the Prostat CPM-720 Charge Plate to the PFM-711A Field Meter and connect the field meter to ground. (See the instrument’s operations manual for detailed instructions.) 2. Connect the analog output of the field meter to the input of the PGA-710 Autoanalyzer using the supplied lead.

  • Page 23: Basic Of Voltage Decay Analysis

    Figure Figure 39: Highlight the Standard Reset and Cutoff Test Voltage that meet test criteria Figure 40: Check the Custom Box and Manually Enter Reset and Cutoff Voltages PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 24 Voltage, Temperature or Humidity. F12 Auto Min Max: Will automatically align display data to vertically utilize the entire chart view using the maximum and minimum data values. PGA-710 Autoanalysis System – How To Measure Guide...

  • Page 25: Understanding Ionization & Measurement Objectives

    Figure 44. Ionizers Supply Charged Gas Molecule to the Air Figure 44 Ions are Distributed by Fan or Compressed Air Diagram courtesy of Arnold Steinman, Technical Director, Ion Systems, Inc PGA-710 Autoanalysis System – How To Measure Guide...

  • Page 26: Offset Voltage & Decay Time Measurement Procedures

    Offset voltage indicates the degree of ion imbalance produced by the ionizer at a distance from its outlet, or at the “work point” where the ionization effect is desired. To measure offset voltage, use the following procedure: PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 27 Insure No Grounded Objects in Air Path Measure Offset Voltage & Document Adjust Offset Voltage As Necessary Portable CPM 12 - 40 Inches Ionizer Ground Worksurface Auditing Ionizer Offset Voltage (Balance) Figure 47: Offset Voltage Measurement Concept PGA-710 Autoanalysis System – How To Measure Guide...

  • Page 28: Understanding Ionization & Measurement Objectives

    Figure 48: Making Offset Measurements on Bench Top Ionizing Blowers 3. Start the Preview mode on the PGA-710 software clicking the green arrow or pressing F5, then start Record to capture the offset voltage data. a. To automatically adjust the chart scale press F11 b.
  • Page 29 6 to 12 test cycles per bench top ionizer audit. Figure 51: Performing Decay Tests on Bench Top Ionizer Temperature Decay Test Cycles Relative Humidity Figure 52: Recorded Decay Data. Note Temperature and Humidity Data PGA-710 Autoanalysis System – How To Measure Guide...

  • Page 30: Analyzing Decay Time Data & Generating Reports

    The horizontal voltage lines at ±1,000 and ±10 volts will be inserted at this point in the process. See Figure 54. Figure 54: “Processed” Decay Test Cycles from ±1,000 to ±10 Volts PGA-710 Autoanalysis System – How To Measure Guide...
  • Page 31 The decay reports and charts may be generated in a standard format as shown in Figure 57, or in a unique “assembled” format Figure 57: Page 1 of Standard Decay Report PGA-710 Autoanalysis System – How To Measure Guide...

  • Page 32: Assembled Decay Charts

    Negative cycles is approximately 5.7 seconds. Figure 58: A Full Size Landscape Chart in the “Assembled” Format NOTE For additional information, review the PGA-710 Operations Manual and industry test standards. Rev: PGA-710 – 1-2011 Format modification: 02-11-2005 PGA-710 Autoanalysis System – How To Measure Guide...
