Dimensions; Vzh088-G/H Single Version; Vzh088-G/H Manifolded Version - Danfoss VZH088-G single Application Manuallines

Application Guidelines
VZH088-G/H single
version
Ø224
Ø220.8
Suction
1"1/8
469.7
max.
93
Ø243
219.5
148
15.1 with
compression
230
190.5
30°
4 holes
Ø19.05
230
190.5
60°
30°

Dimensions

Discharge
7/8"
436.1
78.7
179.9
180.7
154
158
Electrical box

VZH088-G/H manifolded version

Ø224
Ø220.8
Suction
1"1/8
469.7
max.
93
Ø243
219.5
148
15.1 with
compression
oil equalisation
230
Ø32 - 1.75" -
190.5
12UN - 2A
30°
4 holes
Ø19.05
230 190.5
60°
30°
Grommet
HM 8 bolt
Lock washer
Ø 33 mm hole
Flat washer
Steel mounting
sleeve
Rubber grommet
Discharge
7/8"
436.1
59.7 78.7
180.7
158
All dimensions in mm
Nut
FRCC.PC.023.A8.02
154
15 mm
21
