STEVAL-ISB68WA test setup

The evaluation of the STEVAL-ISB68WA kit relies on a suitable wireless power transmitter that could mate with
the coil of the RX module. A good coupling factor is essential for both power transfer efficiency and data
communication reliability between the transmitter and the receiver.
The STEVAL-ISB045V1 wireless power transmitter evaluation kit contains the reference transmitter for the test
setup. The complete test setup is shown in
The receiver is connected to the dongle as per
Note: The transmitter must be configured (through its own GUI) to have a ping frequency of 120 kHz and a 130 kHz
-170 kHz operating frequency range. These parameters are easily unlocked and configured in the "parameters"
window (Figure
UM2693 - Rev 1
Figure
Figure 8. STEVAL-ISB68WA evaluation setup
9).
8.
Figure 7a and placed on the transmitter.
