The terminals for the receiving coil, the output load and the control signals are summarized in
rail and the control interface are already made easily accessible by means of wires terminated with pin header
female connectors
Terminal
J1
J2
J3
J4
J5
J6
J7
J8
J9
UM2693 - Rev 1
(Figure 4).
Table 1. Receiver module terminals
AC input (RX coil)
AC input (RX coil)
VRECT (rectifier output)
Power return (ground)
VOUT power output
INT (digital output)
SCL (digital input)
SDA (digital I/O)
Signal ground
Figure 3. Receiver module top and bottom silkscreen
Signal
UM2693
Wireless power receiver module
Table 1. The output
Wiring color
-
-
-
Black (P1)
Red (P1)
Orange (P2)
Yellow (P2)
Green (P2)
Blue (P2)
