HDMI 4K Bi-Direction Switch
Dear customer
Thank you for purchasing this product. For optimum performance
and safety, please read these instructions carefully before
connecting, operating or adjusting this product. Please keep
this manual for future reference.
IntroduCtIon
This Bi-Directional HDMI switch allows you to plug two high
definition sources into a single HDTV or projector, then switch
between them using a push button on the unit. Or plug one high
definition source in to two HDTV's or projectors, then switch to
show the image on either of the screens. Its compact design
allows you to hidden easily.
IMPortAnt SAFetY InForMAtIon
INTENDED USE
We do not permit using the device in other ways like
described in this user's manual. Use the product only
in dry interior rooms. Not attending to these regulations
and safety instruction might cause fatal accidents, injuries,
Blu-Ray DVD Player
and damages to persons and property. The manufacturer/
supplier assumes no liability for damages caused by failure to
comply with the intended use.
Games Console
C A U T I O N
RISK OF ELECTRIC SHOCK
DO NOT OPEN
an authorized technician when service is required. Disconnect
the product from mains and other equipment if a problem
should occur. Do not expose the product to water or moisture.
Installation Precautions:
Cables must be placed well, where it would not be stepped on
or pinched. Make sure HDMI cables are fully inserted into ports.
To provide sufficient ventilation during use, make sure there is at
least 1 inch of clearance on each side of the device (except the
side where it rests on a flat surface). Do not set up this product
adjacent to a water source or an environment that has excessive
moisture. Place this product on a flat surface and keep it out of
reach of children.
FeAtureS
• 1 HDMI input to 2 HDMI outputs
• 2 HDMI inputs to 1 HDMI output
• No power source needed
• Manual select push button to alternate between modes
• Dual LEDs to display status
• 3 HDMI type A plug female connector
• Supports 7.1 channel of LPCM, Dolby TrueHD and DTS-HD
Master Audio digital audio signals
• Supports HDMI 1.4, HDCP, ARC, CEC signals
• Supports Full UHD 4K up to 3840 x 2160 at 30Hz, 3D 1080p
• Operating Temperature: -15 to +65 C
• Operating Humidity: 5 - 90% RH (no condensation)
• Storage Humidity: 5 to 90% RH (no condensation)
USER'S MANUAL
To reduce risk of
electric shock, this
product should
ONLY be opened by
HDTV
exAMPLe oF 2 InPutS to 1 outPut
Blu-Ray DVD Player
Games Console
exAMPLe oF 1 InPut to 2 outPutS
Blu-Ray DVD Player
PACKAge ContentS
• Main unit x1
• User's Manual x1
Maintenance:
Clean only with a dry cloth. Do not use cleaning solvents or
abrasives.
Warranty:
No guarantee or liability can be accepted for any changes and
modifications of the product or damage caused due to incorrect
use of this product.
In compliance with EU Directive WEEE this product is
marked with this symbol. It means that used electrical
and electronic products should not be mixed with
general household waste. There is a separate
collections system for these products in compliance
with WEEE directive, otherwise contaminative and hazardous
substances can pollute the environment.
With the CE sign, Techly
conformed to the basic European standards and directives
www.techly.com
HDTV
HDTV HDTV
ensures that the product is
®
EN
