Step 7

1.
PWRview should be mounted firmly in the panel
2.
Antenna should be mounted in the knockout with the extension cable
connected to the side of PWRview
3.
Voltage Cable should be connected properly and securely
Black and Red wires to 2 breakers
White wire to neutral to bus bar
4.
CT Connectors should be connected properly and securely
Connectors should be clamped around the mains
Make sure the labels are facing the utility
5.
Turn the main breaker to the 'ON' position. The next steps will guide you
through configuration and confirming the operation of the PWRview meter
PWRVIEW PORT
Voltage Connector
Port 1
Port 2
Port 3*
Port 4*
Antenna connector
NOT E : These are used for additional installation types. Refer to
R E V IE W YOU R WO R K
PWRVIEW CONNECTION
Black
Red
Blue*
White
CT1
CT2
NA
NA
Antenna harness
PANEL CONNECTION
Empty Breaker 1
Empty Breaker 2
No connection
Neutral Bus bar
Utility line
"
NA
NA
Antenna knockout
www.generac.com/service-support/PWRview
PANEL POSITION
Phase A
Phase B
Capped (wire nut)
NA
Phase A
Phase B
NA
NA
Antenna (through encl.)
