Southern States SSB-T Installation Instructions Manual

Single side break disconnect switch

Advertisement

Quick Links

Types SSB-T / SSB-A
(copper)
(aluminum)
Single Side Break
Disconnect Switch
15.5 kV – 72 kV,
1200 A or 2000 A
INSTALLATION &
INSTRUCTION
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSB-T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Southern States SSB-T

  • Page 1 Types SSB-T / SSB-A (copper) (aluminum) Single Side Break Disconnect Switch 15.5 kV – 72 kV, 1200 A or 2000 A INSTALLATION & INSTRUCTION MANUAL...
  • Page 2 Page I The Quality Name in High Voltage Switching...
  • Page 3 Please ensure that you are using the latest installation and maintenance instructions. If you do not understand any part of these instructions or need assistance, contact Southern States Service Division at 770-946-4562 during normal business hours (8:00am – 4:30pm EST, M-F) or 770-...
  • Page 4 The purchaser (“Purchaser”) of certain Equipment (the “Equipment”) identified in the Instruction Manual accompanying these Terms of Use sold by Southern States, LLC (“Southern States”), by Purchaser’s acceptance or Use of Equipment in any way, agrees to the Terms of Use set forth below (the word “Use” herein means receipt, testing, inspection, installation, operation, maintenance and...
  • Page 5 The Quality Name in High Voltage Switching LIMITED WARRANTY Southern States, LLC (“SSLLC”) warrants only to the Warranty Holder (hereinafter defined as the “End User” or the “Immediate Purchaser”, as applicable, pursuant to the terms and conditions of this Limited Warranty as set forth below), that the Product identified below will, upon shipment, be free of defects in workmanship and material for the applicable Warranty Period.
  • Page 6 Page V The Quality Name in High Voltage Switching...
  • Page 7 Page VI The Quality Name in High Voltage Switching Type SSB-T / SSB-A Single Side Break Disconnect Switch 15.5 kV – 72.5 kV, 1200A or 2000A...
  • Page 8: Table Of Contents

    Page VII The Quality Name in High Voltage Switching Table of Contents Chapter Page Summary & Introduction ........................1 Important ............................1 Summary ............................1 Introduction ............................ 2 Product Description ........................... 4 Typical Switch ..........................4 Ratings .............................. 5 Receiving, Handling & Storage ......................6 Receiving &...
  • Page 9 Table 1: Recommended Installation & Maintenance Table .............. 14 Figures Page Figure 1: Typical SSB-T / SSB-A Disconnect Switch & Common Terminology ........4 Figure 2: Hinge End ........................... 7 Figure 3: Contact End – Switch Open ....................7 Figure 4: Blade Shown Fully Open ....................9 Figure 5: Rotating Insulator Bearing ....................
  • Page 10: Summary & Introduction

    Southern States Representative. The contents of this instruction manual should not become part of or modify any prior or existing agreement, commitment or relationship.
  • Page 11: Introduction

    The instructions contained within this manual are necessary for the safe installation, maintenance, and operation of the SSB-T / SSB-A switch. A qualified person, familiar with this of type equipment, should carefully read and follow the instructions.
  • Page 12 Page 3 of 17 Summary & Introduction...
  • Page 13: Product Description

    Page 4 of 17 Product Description Product Description Typical Switch The SSB-T and SSB-A switch consists of the following single pole assemblies: • Live Parts – blades with hinges, terminal pads, and contacts Bases • • Insulators • Interphase & Control Pipes with Hardware Outboard Bearing &...
  • Page 14: Ratings

    60 Hz Continuous Current 2000 A Short-Time Symmetrical 44 kA RMS Withstand (3 sec) Peak Withstand 114 kA C to +50 C Standard Ambient Temperature Rating (-50 C Optional) * 2000 A rating is only available using copper switch (SSB-T)
  • Page 15: Receiving, Handling & Storage

    Storage All components of the SSB-T / SSB-A single side break disconnect switch are suitable for outdoor use and do not have any special storage requirements. If a motor operator is furnished be sure to connect the heater circuit, using the provided external wiring, while the unit is in storage.
  • Page 16: Installation & Adjustment Procedures

    Page 7 of 17 Installation & Adjustment Procedures Installation & Adjustment Procedures Preferred Switch Assembly Method When insulators are shipped installed on the switch, proceed to page 13 - Mounting 1.1. Disconnect Switch onto the Structure. Set up bases at ground level on transverse beams (base supports): 1.2.
  • Page 17: Mounting Disconnect Switch Onto The Structure

    Page 8 of 17 Installation & Adjustment Procedures Mounting Disconnect Switch onto the Structure Rigging used to hit the poles should be attached to the base with steadying guides attached to prevent lipping of the switch pole. Do not lift the switch by attaching to the live parts.
  • Page 18: Adjustment

    Page 9 of 17 Installation & Adjustment Procedures Adjustment Adjustment of switch in closed position If the blade does not align properly with the contact, improper operation and possible damage will result. Check to make sure all bolts are tight. Variances in insulators may cause some misalignment, which will require shimming of the insulator to obtain proper alignment.
  • Page 19: Adjustment Of Contact Pressure

    Page 10 of 17 Installation & Adjustment Procedures Adjustment of contact pressure The correct contact pressure has been pre-set at the factory and should not need adjustment. If for some reason you find it necessary to adjust the contact pressure, follow these rules: •...
  • Page 20: Arcing Horn Adjustment

    Page 11 of 17 Installation & Adjustment Procedures Arcing Horn Adjustment If arcing horns are supplied and adjustment is required proceed as follows: Operate Switch. • • Blade should make light to firm sliding contact along the straight portion of the horn until the switch is fully closed.
  • Page 21: Operating Mechanism Adjustment

    Page 12 of 17 Installation & Adjustment Procedures Operating Mechanism Adjustment If a motor operator Is used, DO NOT USE ELECTRICAL OPERATION until the following adjustments are completed. NOTE: The setting of the adjustable arm on the Operating Mechanism Drawing is a calculated dimension.
  • Page 22: Mounting Disconnect Switch Onto The Structure

    Page 13 of 17 Mounting Disconnect Switch onto the Structure Rigging used to hit the poles should be attached to the base with steadying guides attached to prevent lipping of the switch pole. Do not lift the switch by attaching to the live parts.
  • Page 23: Recommended Inspection & Maintenance

    Recommended Inspection & Maintenance Recommended Inspection & Maintenance The SSB-T and SSB-A have been designed to operate with minimal maintenance. Periodic inspection is important for satisfactory operation. Frequency of inspection and maintenance depends on the installation site, weather and atmospheric conditions, experience of operating personnel and special operation requirements.
  • Page 24: Patrolling Inspection (6 Months)

    Page 15 of 17 Recommended Inspection & Maintenance Patrolling Inspection (6 Months) The patrolling inspection is a largely visual inspection on an energized unit in service. The frequency of the inspection is determined by the local conditions and policies of the owner of the equipment.
  • Page 25: Appendix

    Page 16 of 17 Appendix Appendix Appendix A: Operating Mechanism Installation Manual and Motor Operated These switches are designed to be opened and closed as a three-phase unit by a system of pipes that translates the rotation movement of an operator on the ground - whether manual or motor - to simultaneous rotation of the end insulator of each switch pole.
  • Page 26: Appendix B: General Installation Notes

    Page 17 of 17 Appendix Appendix B: General Installation Notes When a switch uses an auxiliary switch arm, installation will be easier if this pole is adjusted before installing the interphase pipe. This will eliminate trying to coordinate and adjust all three poles at once.
