DEVIreg™ 850 IV
1�2

General use

The DEVIreg™ 850 is operated via 3 buttons and an alpha numeric display capable of
displaying information in various languages.
Buttons
The functions of the 3 buttons are:
Info
Next
Enter
Besides the normal function of the buttons, some special combinations are important to
the user:
Return to home of menu system:
Master reset: Restore factory defaults AND
delete installed systems (In case of insolvable
problems due to a wrong choice of language,
etc.)
Display
The following icons have a special meaning:
This animated icon is shown, when the system is heating. When the icon is
blinking the system wants to heat, but is paused (system has low priority).
This icon is shown, when the system has detected moisture, and the tempera-
ture is above the melting temperature.
This icon is shown, when the system has detected snow or ice, and the tempera-
ture is below the melting temperature.
The DEVIreg™ 850 can simultaneously control up to 2 different systems. These 2 systems
are referred to as System A and System B. The DEVIreg™ 850 gives the user the opportu-
nity to view the current status of the systems. The status can be shown in 2 different ways.
Installation instruction
Shows additional information / help (Only active when lit)
Next menu entry / next line / next letter
Confirm / select
Hold for 2 seconds
Hold + for 8 seconds
