System Contents

After unpacking, you will have the following items:
AC Adapter
8GB
8 GB micro SD Card
(Comes installed)
Camera
Screw/Anchor Kit
Camera Bracket
Rechargeable 18650 Batteries
CAMERA INSTALLATION + SETUP
CAMERA INSTALLATION
1 Secure the multi-position Camera
Bracket using the two screws. If
needed, two anchors are also
included.
NOTE: Avoid pointing a camera directly at any bushes or tree branches or objects
that may naturally move due to winds.
3 Connect the small end of the A C
adapter to the camera's USB
Jack. You can also use batteries
as described in the owner's
manual.
Recommendations for best system performance:
• Apple: iOS 7.0 or above.
• Android: Android TM smartphone or tablet (version 4.3 or above).
• Storage: Class 10 microSD memory card (up to 32 GB).
• Bandwidth: 512Kbps or above upload/download speed suggested.
BACK cover
— 5 —

INTRODUCTION

SensorCam
Loosen the T-Bolt on the Camera
2
Bracket and adjust viewing angle.
When set, rotate clockwise until
tight. Slide the Camera Bracket
onto the screws.
4 Plug into electrical outlet.
Use the bottom mount or the rear
mount to secure the camera to the
Camera Bracket and tighten.
Model AWFB15
QUICK START GUIDE
Wireless Made Simple.
Front cover
FO LD
Quick Start Guide
APPLE REMOTE VIEWING APPLE REMOTE VIEWING
APPLE DEVICE SETUP
SightHD
1 From your smart device, DOWNLOAD and INSTALL the free ALC SightHD App.
Apple remote vie
2 Plug camera into an electrical outlet (allow the camera up to 90 seconds to boot up).
3 On your Apple device, open the Settings App. Tap Wi-Fi and under Choose A Network, select the H
being redone.
4 When asked for a password, enter, "12345678". Tap Join to connect.
FREE
5 Now Launch the ALC SightHD App and the Setup Wizard will appear.
6 Tap to start the Wizard.
7 Once the screen indicates the camera is connected, tap Live View.
8 Once the camera is found, the screen will show a Live View briefly before moving to a setup screen
9 At the next screen enter a new password and remember it or write it down. Tap Wi-Fi Setting.
10 Select your home network from the menu, and then enter your home network's Wireless Password
11 The system will reboot the camera. The reboot will be complete when the App finishes counting do
Tap still image for live video.
ANDROID REMOTE VIEWING
ANDROID DEVICE SETUP
From your smart device, DOWNLOAD and
1
INSTALL the free ALC SightHD App.
Connect the SensorCam to an outlet as described
2 SightHD
in this guide. The LED should blink red and blue.
3 On your smartphone or tablet, go to Wi-Fi Settings.Tap
Wi-Fi and select the SensorCam- XXXXX Network. If a
password is needed, enter"12345678".
4 Launch the ALC SightHD app. Tap Set Up Wizard on
screen for direct wireless connection of camera to App.
5 Tap Battery Cameras and then tap Next.
Select your network as per the instructions on your device
6
and then enter your password. When done, tap Next.
Tap OK. The Change Password screen will appear. Enter a
7
password and remember it or write it down for future use.
Tap OK.
FREE APP DOWN
8 Tap Not Now to set up the cloud later. Tap OK.
Tap still image for live video.
9
NOTE: Screen-shots and icons may vary due to continuous updates to App and software developm
LIVE VIEW RECORDING PLAYBACK
on MicroSD CARD*
1 Tap Edit Setting, tap Setting and
1 The MicroSD Card comes pre-installed in
the battery compartment. You can also
record onto the cloud, if set up. Select the Start and Stop date and time
2
and tap OK.
3 Tap the FILE that you want to playback f
*MicroSD card (pre-installed) is
required to record video to
camera.
2 Manually RECORD video from Live
View by tapping Record icon. The
App will record for five to 30
seconds depending on the
Recording Cycle setting.
Motion Recording
Motion Enable is the default setting. To
change the MOTION ACTIVATED
RECORDING, go to Edit Setting, tap
Setting and then tap Advanced.
The Advanced Settings will ask for the
admin password; default password is
123456. You can change the default
password within the Advanced Settings.
NOTE: Do not submerge camera in water. STRANGULATION HAZARD: Infants have STRANGLED F
in power cords. Keep power cords more than 3 feet away from cribs. When using your equipment,
M
always follow basic safety precautions to reduce the risk of fire, electric shock and injury to persons.
w
Illustrations are for reference only. Actual product specifications may vary.
For additional precautions and product information, please see owner's manual at
www.ALCWireless.com/support.
