F3 Compact Main Components
Figure 3 identifies the main components of the F3 Compact.
Handle Assembly
Shaft Hinge
Upper Camlock
Lower Camlock
Coil
8 | General Description and Preparation
Armrest Strap
Armrest
Coil Pivot Assembly
Skid Plate
Figure 3: F3 Compact main components
Upper Shaft
Middle Shaft
Lower Shaft
F3 Compact Operations Manual
Battery
Compartment
Test Piece
Earset Connector
Main Body
Controls
