- Page 1 SBN Pendant Pushbutton Station Instruction Manual Part Number: 126-11173 R2 October 2019 ©Copyright 2019 Magnetek Material Handling...
- Page 2 Page Intentionally Left Blank...
-
Page 3: Table Of Contents
Table of Contents Service Contact Information ........................4 Preface and Safety ............................5 Product Safety Information ........................5 Product Warranty Information ........................5 DANGER, WARNING, CAUTION, and NOTE Statements ............... 6 Product Overview and Features ........................ 8 Installation and Wiring ..........................10 Installation Precautions ........................... -
Page 4: Service Contact Information
Service Contact Information For questions regarding service or technical information contact: Magnetek Material Handling N49 W13650 Campbell Drive Menomonee Falls, WI 53051 Distributed by Tri-State Equipment Company Inc. 314-869-7200 Telephone: www.tsoverheadcrane.com Website: sales@tsoverheadcrane.com E-mail: Fax Numbers: 314-869-7200 Main: 314-869-7200 Sales:... -
Page 5: Preface And Safety
It is the responsibility of the owners, users and operators of the Magnetek Products to know, understand and follow all of these requirements. It is the responsibility of the employer to make its employees aware of all of the above listed requirements and to make certain that all operators are properly trained. -
Page 6: Danger, Warning, Caution, And Note Statements
DANGER, WARNING, CAUTION, and NOTE Statements Read and understand this manual before installing, operating, or servicing this product. Install the product according to this manual and local codes. The following conventions indicate safety messages in this manual. Failure to heed these messages could cause fatal injury or damage products and related equipment and systems. - Page 7 Do not operate an SBN Pendant Pushbutton Station unless you are fully trained and qualified to operate the overhead material handling system of which this SBN is a component. For applications other than overhead cranes and hoists, consult Magnetek at 1-800-288-2178. WARNING Read the entire contents of this manual before you install or use the SBN Pendant Pushbutton Station.
-
Page 8: Product Overview And Features
Product Overview and Features Figure 1: SBN-8-WHS Pendant SBN Pendant Station Manual October 2019 Page 8 of 19... - Page 9 The SBN pendant pushbutton station product features: Polycarbonate enclosure Silicone rubber button hoods Captive stainless steel cover screws and molded in cover nuts External key ring for strain relief cable attachment Internal strain relief clamp Pre-wired common circuit NEMA 4X rating (see Table 1 for NEMA Rating Designation) Visible switch contacts with clear covers Table 1: NEMA Rating Designation A300 Information –...
-
Page 10: Installation And Wiring
Installation and Wiring Installation Precautions Do not expose the unit to cold blasts of air that might cause condensation (e.g., from an air conditioner). Do not expose the unit to cleaning solvents that will penetrate and damage the unit's enclosure. Do not use cable that is split or cracked. -
Page 11: Enclosure Disassembly
Enclosure disassembly 1. Remove the back cover by loosening the cover screws. 2. Remove the top cover by loosening its two screws. This makes feeding the cable through the top cable entry gland easier. Wiring NOTE: Ensure that only type SOW cable is used for the pendant. NOTE: Use copper conductors only for terminal wiring. -
Page 12: Enclosure Reassembly
10. The SBN pendant is double insulated. No metal part extends from inside of the enclosure to the outside. Because of this, grounding inside the pendant is not necessary. However, because of the possibility that water could enter the pendant through damaged parts or cable, it is recommended that a ground wire be left extending to the bottom. -
Page 13: Strain Relief Installation When Using Cable With Molded In Strain Relief Cables
5. Pull the auxiliary cable armor down to cover the cable and cable gland area. Wrap the auxiliary cable armor with self-fusing electrical tape (non-adhesive) to press the flexible auxiliary cable armor against the cable and cable gland. Overwrap the self-fusing tape with vinyl adhesive electrical tape to protect the area. -
Page 14: Lens And Legend Replacement
Figure 4: Strain Relief Installation When Using Non-Strain Relief Round Cable Lens and Legend Replacement Using a small screwdriver, pry the lens out of the button hood by inserting the blade between the lip of the hood and the lens. Be careful not to damage the button hood. Remove the legend and replace with the selected word or symbol from the legend sheet. -
Page 15: Operation
Operation General Do not place or drop the pendant in water. Do not let the pendant slam into objects or people. Do not move switches beyond their travel limits. Regular Pre-Operation Inspection – Perform at least monthly Before using a pendant station: Ensure that the unit’s exterior is in good condition with no cracks or sharp edges. -
Page 16: Safe Crane Operating Procedures
Safe Crane Operating Procedures How to operate a crane is beyond the scope of this manual, but a few precautions include: Before picking up a load or making a move, ensure that the path of motion for the operator and the load is clear. -
Page 17: Appendix A - Cable Armor
Appendix A – Cable Armor NOTE: Please refer to Shinkoh Instruction Manual #SB06151 for more information, if required. Figure 6: Cable Armor Types and Cutting Points Type and Dimensions There are four types of cable armor, which are made for specific SBN models. The models for each type are listed in Table 2, and the # symbol refers to the point where the cable armor should be cut and removed (see Figure 6). -
Page 18: Appendix B - Pendant Switch Schematics
Appendix B – Pendant Switch Schematics Distributed by Tri-State Equipment Company Inc. Email: sales@tsoverheadcrane.com Web: www.tsoverheadcrane.com PH: 314-869-7200 | FAX: 314-869-7226 SBN Pendant Station Manual October 2019 Page 18 of 19... - Page 19 SBN Pendant Pushbutton Station Instruction Manual October 2019...
