Summary of Contents for Freescale Semiconductor TWR-K60N512
- Page 1 Quick Start Guide for TWR-K60N512 TOWER SYSTEM TWR-K60N512 Low-power MCU with USB, Ethernet and security...
- Page 2 Figure 1: Front Side of TWR-K60N512 Module Not Including TWRPI. TWR-K60N512 The TWR-K60N512 microcontroller module is part of the Freescale Tower System, a modular development platform that enables rapid prototyping and tool re-use through reconfigurable hardware. Take your design to the next level and begin constructing your Tower System today by visiting freescale.com/tower for...
- Page 3 Quick Start Guide for TWR-K60N512 TOWER SYSTEM SD Card Socket Potentiometer VBAT (RTC) Battery Holder Figure 2: Back Side of TWR-K60N512 Module.
- Page 4 TOWER SYSTEM Step-by-Step Installation Instructions In this Quick Start Guide, you will learn how to set up the TWR-K60N512 module and run the default demonstration. STEP STEP Install the Software Tilt the Board and Tools Tilt the board side to side to see the LEDs on E1–E4 light up as it is...
- Page 5 Quick Start Guide for TWR-K60N512 TOWER SYSTEM STEP Explore Further by Conducting Lab 1: TWR-K60N512 Quick Start Demo Explore all the features and capabilities of the pre-programmed demo by reviewing the lab document located at freescale. com/TWR-K60N512. STEP Learn More...
-
Page 6: Jumper Options
TOWER SYSTEM Jumper Options The following is a list of all the jumper options. The default installed jumper settings are shown in bold. Jumper Option Setting Description MCU Power Connect on-board 3.3V supply to MCU Connection Isolate MCU from power (connect an ammeter to measure current) VBAT Power Connect VBAT to on-board 3.3V supply... - Page 7 Quick Start Guide for TWR-K60N512 TOWER SYSTEM Jumper Option Setting Description JTAG Board Connect on-board 5V supply to JTAG port Power Connection (supports powering board from JTAG pod supporting 5V supply output) Disconnect on-board 5V supply to JTAG port IR Transmitter...
- Page 8 TOWER SYSTEM To learn more about the TWR-K60N512 and other Freescale Kinetis microcontroller products, please visit freescale.com/TWR-K60N512, freescale.com/Kinetis and freescale.com/Tower. Freescale, the Freescale logo and CodeWarrior are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. Flexis, Kinetis and Processor Expert are trademarks of Freescale Semiconductor, Inc.
