Graco A Series Operations & Parts List

Operation - Parts List
Texture Flex Head and Pole
Spray Applicators
U.S. Patent Pending
Model 24B945, Series A
Texture Flex Head Spray Applicator
Model 24B944, Series A
Pole Spray Applicator
1000 psi (6.9 MPa, 69 bar) Maximum Fluid Working Pressure
100 psi (0.7 MPa, 7 bar) Maximum Air Pressure
IMPORTANT SAFETY INSTRUCTIONS
Read all warnings and instructions in this
manual. Save these instructions.
Pressure Relief Procedure
To reduce the risk of serious bodily injury, including elec-
tric shock and splashing fluid in the eyes, follow this pro-
cedure whenever you stop spraying.
1. Shut off pump and sprayer.
2. Open sprayer drain valve.
3. Close applicator air valve.
- For Water-Based Materials Only -
Working Pressure
To reduce the risk of component rupture and serious
bodily injury, never exceed 1000 psi (69 bar) FLUID
WORKING PRESSURE to the applicator. Do not
exceed the maximum working pressure of any other
component in the system.
Fluid and Solvent Compatibility
Do not use 1,1,1-trichloroethane, methylene chloride,
other halogenated hydrocarbon solvents or fluids con-
taining such solvents in this equipment, which contains
aluminum and/or zinc parts. Such use could result in a
serious chemical reaction, with the possibility of explo-
sion, which would cause death, serious bodily injury
and/or substantial property damage.
