GENERAL INFORMATION

The Monsoon Monitor is a manually operated monitor designed for master stream flows. The Monsoon's unique patented segmented
waterway allows water to make very few turns as it travels through the monitor resulting in low friction loss and a far reaching effective
stream. Elevation range is 90 degrees above horizontal to 45 degrees below. The manual model has 360 degree continuous horizontal
rotation with field changeable stops at 45, 90, and 135 degrees either side of a center position.
The Monsoon RC is an electric remote controlled monitor that has all the benefits of the Monsoon monitor with the addition of powered
operation. The Monsoon RC comes with a factory installed control panel mounted on the monitor for controlling horizontal rotation,
elevation, and nozzle pattern. Knobs for manual override are provided on the horizontal rotation and elevation drive. Remote control of a
TFT ER nozzle is enabled by plugging into the factory installed nozzle power/communication cable. Electric drives and control box are
waterproof.
3.1

SPECIFICATIONS

Weight
Minimum Flow Area (4" Inlet)
Minimum Flow Area (3" Inlet)
Maximum Operating Pressure
Nominal Operating Voltage
Maximum Voltage
Operating Temperature Range of
Fluid
Storage Temperature Range
Maximum Torque (Elevation)
Maximum Torque (Horizontal)
Speed (Elevation)
Speed (Horizontal)
Materials
.0
©Copyright Task Force Tips LLC 2004-2020
MANUAL
US METRIC
25 lbs 11.4 kg
2 2
8.3 in 24.5 cm
2 2
7.07 in 45.6 cm
200 psi 14 bar
33°F to 120°F / 1°C to 50°C
-40 to 150°F / -40 to 65°C
ANSI A356.0-T6 Aluminum, Stainless, Nylon
Table 3.1
6
ELECTRIC
US METRIC
37 lbs 16.8 kg
2 2
8.3 in 24.5 cm
2 2
7.07 in 45.6 cm
200 psi 14 bar
12 or 24 VDC (auto sense)
32 VDC
80 ft·lbs 110 N·m
60 ft·lbs 80 N·m
6 deg/sec
12 deg/sec
