STEP 6
Rotate clamps to desired position and tighten
Screws until finger tight. Maintain equal spacing
between Clamp ends.
Tighten Screws one additional turn using a 5/32"
(4mm) hex wrench. Alternate Screws each
half-turn.
To avoid damage to the monitor, ensure Clamps
do not interefere with RC monitor Power/Com
cable and that Screws are not overtightened.
©Copyright Task Force Tips LLC 2004-2020
EQUAL SPACING
Figure 4.4B
16
TIGTHEN ONE TURN
PAST FINGER TIGHT
ALTERNATE BOLTS
WITH EACH HALF TURN
LIY-200 November 5, 2020 Rev19
