MANUAL OVERRIDE KNOB
FOR HORIZONTAL ROTATION
WIRE SKIRT
Figure 3.4D
Monsoon RC for Ladder or Platform
©Copyright Task Force Tips LLC 2004-2020
MANUAL OVERRIDE KNOB
FOR ELEVATION
MANUAL OVERRIDE WRENCHING HEX
ELEVATION GEAR MOTOR
HORIZONTAL ROTATION
GEAR MOTOR
Figure 3.4C
Monsoon RC Monitor
Anti-Back-Drive
Gearbox
Figure 3.4E
Monsoon RC for Ladder
9
POWER AND
COMMUNICATION CORD
30 FEET
(9 METERS)
MONITOR MOUNTED
CONTROL STATION
Figure 3.4F
Monsoon RC Standard Model
