Operation And Monitoring From The Browser; Addresses; Homepage - W&T IP-Watcher 2x2 Digital PoE Manual

W&T
IP-Watcher 2x2 Digital PoE

3 Operation and Monitoring from the Browser

Once the IP-Watcher has been configured with the required
basic network parameters and connected to the network, you
may further configure and operate/monitor the device from
your browser.

3.1 Addresses

There are four pages which you can directly address from the
browser. In the following the URLs are briefly explained and
listed.
The homepage automatically refreshes to show the status of
the configured alarms and makes it possible for the logged in
user to confirm alarms using software acknowledgement:
http://<IP address of the IP-Watcher>/home.htm
The following link opens the homepage, as described above,
along with the configuration menu:
http://<IP address of the IP-Watcher>/index.htm
The user page displays - also automatically refreshed - the
status of the IOs and all alarms:
http://<IP address of the IP-Watcher>/user.htm
Diagnostics messages can be retrieved at the following
address:
http://<IP address of the IP-Watcher>/diag.htm

3.2 Homepage

The homepage, which can be opened using address
http://<IP address of the IP-Watcher>/home.htm
25
