sPeCifiCATiONs

Dimensions
height 3U eurorack standard height
width 36 HP
Depth 44 mm/ 1.75 in (from rear of front panel to top of fpga board power connector)
Power Consumption
+12V 270 mA.
-12V 24 mA.
+5V 0 (not connected)
Voltage levels
iNL, iNR, - 5 to +5 Volts
OUTL, OUTR
CLK (in and out) 0 to +5 volts
Cv inputs 0 to +10 volts
34
CHANGe LOG
Version 1.09:
ADDED: Mod B Only Destination for Rhythm Delay Time (with range set by CLK DIV - repeats
every 4 levels of CLK DIV) (Mod A can still be set to Delay Clock Div)
ADDED: Reduce MOD LEVEL amplitude by a factor of 8 when the encoder is pressed while the
mod pages are displayed. This is to give more subtle modulations.
CHANGE: The preset load/save changed so that now the last preset to be saved or loaded is
loaded on power up
FIXED: Routing was not loaded all the time from preset
FIXED: Preset Loading Screen flashes to boot screen and hangs
FIXED: Randomizer on some list based values was giving out of range values
Version 1.05:
ADDED: an additional mode, called "Random", has been added to the RANDOMIZE function.
This selects a randomize mode at random from the other 15 modes.
ADDED: an entry labelled DLY CLK/T has been added to the comb CLK SRC list.
ADDED: five new values have been added to the list of MOD A/B destinations.
ADDED: Automatic Gain Control (AGC) circuits have been added to the rhythm delay feedback,
comb feedback, and overall output pathways. This prevents runaway feedback and the result-
ing distortion.
CHANGED: by popular demand the word "PILE", present on the original front panel design, has
been replaced by the word "STACK". The functionality has not been changed.
CHANGED: now when you hold down the LOAD button when pressing the rotary encoder while
loading a preset, just the parameters of the active effects (as stored in the preset) will be load-
ed. This was the default behaviour before, now the default behaviour is to load all parameters.
IMPROVED: The interpolation used in the rhythm delay and comb modulation LFOs has been
improved, reducing clicks and artifacts when modulating the delay lines.
CORRECTION: the value 671 msec has been added to the list of GRAIN SIZE values. This was left
out in the previous version of the manual.
