- Page 1 USER MANUAL VIA VDLM-100-B Deep Learning Machine For 4 x GPU Cards 1.00-03032020-154700...
- Page 2 VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice.
- Page 3 Notification In the EU, this symbol means that this product must not be disposed of with household waste. It is your responsibility to bring it to a designated collection point for the recycling of waste electrical and electronic equipment. For more information, please contact your local waste collection center or your point of purchase.
-
Page 4: Table Of Contents
VIA VDLM-100-B User Manual Table of Contents 1. Product Overview ......................1 Server System Layout ........................... 1 1.2 Product Specifications .......................... 3 1.2.1 Barebone ............................3 1.2.2 Mainboard ............................. 6 Mainboard Back Panel I/O ........................7 1.3.1 LAN Port LED Indications........................ 7 2. BIOS Setting ........................10 Main Screen ............................ - Page 5 VIA VDLM-100-B User Manual List of Figures Figure 1: VIA VDLM-100-B layout diagram front view ..................1 Figure 2: VIA VDLM-100-B layout diagram top view ................... 1 Figure 3: VIA VDLM-100-B layout diagram rear view ..................1 Figure 4: VIA VDLM-100-B mainboard diagram top side ..................2 Figure 5: VIA VDLM-100-B mainboard diagram back panel I/O ................2 Figure 6: Mainboard back panel I/O ........................7 Figure 7: LAN port LED indications ........................7 Figure 8: LAN port (LAN1, LAN2) LED indications diagram ................. 8 Figure 9: Main Screen diagram ........................10 Figure 10: Advanced Screen diagram .........................
- Page 6 VIA VDLM-100-B User Manual List of Tables Table 1: Mainboard back panel I/O description ....................7 Table 2: IPMI LAN port LED indications tables ....................8 Table 3: 10G LAN port (X550_LAN1, X550_LAN2) LED indications tables ............8 Table 4: Speaker type connections table ......................9...
-
Page 7: Product Overview
VIA VDLM-100-B User Manual 1. Product Overview Server System Layout Figure 1: V IA VDLM-100-B layout diagram front view Figure 2: V IA VDLM-100-B layout diagram top view Figure 3: V IA VDLM-100-B layout diagram rear view... -
Page 8: Figure 4: Via Vdlm-100-B Mainboard Diagram Top Side
VIA VDLM-100-B User Manual Figure 4: V IA VDLM-100-B mainboard diagram top side Figure 5: V IA VDLM-100-B mainboard diagram back panel I/O... -
Page 9: Product Specifications
VIA VDLM-100-B User Manual Product Specifications 1.2.1 Barebone System Form Factor - 4U Server Chassis Dimensions - 596mm x 430.4mm x 174.8mm Front Panel Buttons - Power Switch - System Reset LEDs - Power Status LED - HDD - System Fail LED - LAN Activity LEDs I/O Ports - 2 USB 3.0 ports... - Page 10 VIA VDLM-100-B User Manual Ethernet Interface - 10Gbps/1000Mbps/100Mbps LAN Controller - 2 RJ-45 10GbE by Intel X550-AT2 - Supports Wake-On-LAN - Supports Energy Efficient Ethernet 802.3az - Supports Dual LAN with Teaming function - Supports PXE - LAN1 supports NCSI Management BMC Controller - ASPEED AST2500 IPMI Dedicated GLAN - 1 Realtek RTL8211E for dedicated management GLAN Features - NMI Graphics Controller - ASPEED AST2500 VRAM - DDR4 256MB...
- Page 11 VIA VDLM-100-B User Manual Audio OH/Fan Fail LED System BIOS BIOS Type - 256Mb AMI UEFI Legal BIOS BIOS Features Hardware Monitor Temperature - CPU Temperature Sensing - System Temperature Sensing - CPU/Rear/Front Fan Tachometer - CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) - CPU/Rear/Front Fan Multi-Speed Control Voltage - Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, 1.05V_PCH, +BAT, 3VSB, 5VSB Environment Temperature - Operating temperature: 10°C ~ 35°C - Non-operating temperature: -40°C ~ 70°C Notes: 1. As the operating temperature provided in the specifications is a result of the test performed in VIA’s chamber, a number of variables can influence this result. Please note that the working temperature may vary depending on the actual situation and environment. It is highly recommended to execute a solid testing program and take all the variables into consideration when building the system. Please ensure that the system runs well under the operating temperature in terms of application.
-
Page 12: Mainboard
VIA VDLM-100-B User Manual 1.2.2 Mainboard Supports OS - Microsoft Windows® (Server OS) Server 2012 R2 (64 bit) Server 2016 (64 bit) Server 2019 (64 bit) - Microsoft Windows® (Client OS) Windows 10 (64 bit) - Linux® Red Hat Enterprise Linux Server 6.9 (64 bit) / 7.6 (64 bit) CentOS 6.9 (64 bit) / 7.6 (64 bit) SUSE Enterprise Linux Server 12 SP4 (64 bit) / 15 SP1 (64 bit) FreeBSD 11.3 (64 bit) Ubuntu 16.04 (64 bit) / 18.04 (64 bit) - Virtual VMWare ESXi 6.5 u1 / vSphere 6.5 u1 Citrix XenServer 7.5 Win hyper-V Server 2016 Enviornment Temperature - Operating temperature: 10°C ~ 35°C - Non-operating temperature: -40°C ~ 70°C Warning: This motherboard supports Wake from on Board LAN. To use this function, please make sure that the “Wake on Magic Packet from power off state” is enabled in Device Manager > Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is enabled in UEFI SETUP UTILITY > Advanced > ACPI Configuration. After that, onboard LAN1&2 can wake up S5 under OS. Warning: If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Windows® Hardware Quality Lab (WHQL) certification tests. If you install the drivers only, it will pass the WHQL tests. -
Page 13: Mainboard Back Panel I/O
VIA VDLM-100-B User Manual Mainboard Back Panel I/O Figure 6: M ainboard back panel I/O Item Description VGA Port (VGA1) UID Switch (UID1) USB 3.1 Gen1 Ports (USB3_1_2) PS/2 Mouse/Keyboard Port USB 3.1 Gen2 Port (USB31_TC_1) USB 3.1 Gen1 Port (USB31_TA_1) LAN RJ-45 Port (IPMI_LAN) Optical SPDIF Out Port (SPDIF1) Rear Speaker (Black) Central/Bass (Orange) Microphone (Pink) Front Speaker (Lime) Line-In (Light Blue) LAN RJ-45 Port (X550_LAN1) LAN RJ-45 Port (X550_LAN2) Table 1: Mainboard back panel I/O description 1.3.1 LAN Port LED Indications There are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port... -
Page 14: Figure 8: Lan Port (Lan1, Lan2) Led Indications Diagram
VIA VDLM-100-B User Manual Dedicated IPMI LAN Port LED Indications Activity/Link LED Status Description No Link Blinking Yellow Data Activity Link Speed LED Status Description 10Mbps connection or no link Yellow 100Mbps connection 1Gbps connection Table 2: IPMI LAN port LED indications tables There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. SPEED LED ACT/LINK LED LAN Port Figure 8: L AN port (LAN1, LAN2) LED indications diagram 10G LAN Port (X550_LAN1, X550_LAN2) LED Indications... - Page 15 VIA VDLM-100-B User Manual If you use a 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”. See the table below for connection details in accordance with the type of speaker you use. Audio Output Front Speaker Rear Speaker Central/Bass Line In Channels (No. 12) (No. 9) (No. 10) (No. 13) √ √ √ √ √ √ √ √ √ √ Table 4: Speaker type connections table...
-
Page 16: 2. Bios Setting
VIA VDLM-100-B User Manual 2. BIOS Setting This section will show you how to set up the BIOS setting. Main Screen Once you have enter the UEFI SETUP UTILITY, the main screen will appear on display the system overview. The Main screen provides system overview information and allows you to set the system time and date. Figure 9: M ain Screen diagram Advanced Screen Figure 10: Advanced Screen diagram Warning: Setting the wrong values in this section may cause the system to malfunctions. -
Page 17: Cpu Configuration
VIA VDLM-100-B User Manual In this section, you may set the configurations for the following items: CPU Configuration, DRAM Configuration, Chipset Configuration, Storage Configuration, ACPI Configuration, USB Configuration, Super IO Configuration, Serial Port Console Redirection, H/W Monitor, Runtime Error Logging, Intel SPS Configuration, Intel(R) VMD Technology, Intel(R) Virtual RAID on CPU and Instant Flash. 2.2.1 CPU Configuration Figure 11: CPU Configuration Screen diagram Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved. -
Page 18: Exit Screen
VIA VDLM-100-B User Manual Exit Screen Figure 12: Exit Screen diagram Save Changes and Exit When you select this option, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, the following message “Discard changes and exit setup?” will pop-out. Press <ESC> key or select [Yes] to exit the UEFI SETUP UTILITY without saving any changes. Discard Changes When you select this option, the following message “Discard changes?” will pop-out. Press <F7> key or select [Yes] to discard all changes. Load UEFI Defaults Load UEFI default values for all the setup questions. F9 key can be used for this operation. Boot Override These items displays the available devices. Select an item to start booting from the selected device. - Page 19 LIMITED WARRANTY VIA warrants to the purchaser of this Product and its solution in its original sealed packaging. The Product will substantially conform to VIA's publicly available specifications, and if the Products is properly used and installed, it will not stop working because of defects in material and manufacture for 1 year from the purchase date of (1) the Product in its original sealed packaging or (2) the warranty docunent. If the Product fails to conform to the above warranty during the warranty period, VIA, at its option, will: REPLACE the Product; OR REPLACE it with a new or reconditioned Product. WHAT THIS LIMITED WARRANTY DOES NOT COVER: • any costs associated with the repair or replacement of the Product, including costs of removal or replacement of the Product; • damage to the Product, or errors or malfunctions in the Product, due to accident, abnormal electrical,mechanical or enviromental conditions, use contrary to product instructions, misuse, neglect, alteration, mishandling, repair, im proper installation or testing, combinations with incompatible products or any third party virus, infection, worm or similar malicious code; • that the Product will protect against all possible security threats, including intentional misconduct by third parties; • any Product which has been modified or operated outside of VIA's publicly available specifications, or the original identification markings have been removed, altered or obliterated. For further information, please reference your WARRANT DOCUMENT. If you need technical help, contact point of purchase or VIA Technologies, Smart Cities.
