NCR 7402-K568 Kit Instructions
NCR 7402-K568 Kit Instructions

NCR 7402-K568 Kit Instructions

Wall mount bracket with wide keyboard shelf

Advertisement

Quick Links

7402‐K568


Wall Mount Bracket
with

Wide Keyboard Shelf
Kit Instructions

Issue B

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7402-K568 and is the answer not in the manual?

Questions and answers

Summary of Contents for NCR 7402-K568

  • Page 1 7402‐K568     Wall Mount Bracket with   Wide Keyboard Shelf Kit Instructions    Issue B ...
  • Page 2: Revision Record

    Revision Record Issue Date Remarks A  May 2006  First issue  B  May 2007  Added 7404 support            ...
  • Page 3 7401-K568 Introduction Note: This kit is the RoHS version of 7402‐K543.  This kit is used to mount an NCR 7402/7404 w/Fixed Angle Mount to a  wall. The mount has a sliding keyboard Shelf for the following  keyboards (ordered separately):  • 2336‐K100 Cherry Keyboard w/Trackball; PS/2 Serial.  • 2336‐K634  Cherry Keyboard w/Trackball; USB  • 2336‐K212  Rugged Storm Keyboard US Layout; USB  23430   ...
  • Page 4: Installation Procedure

    7401-K568 Installation Procedure 1. Release the Cable Chain from the Cable Chain Bracket by pressing  down and pivoting out on the last link in the Cable Chain Link as  shown below.  Cable Chain Bracket Press Downward Pivot Outward   18522a...
  • Page 5 7401-K568 2. Remove the screws that secure the Keyboard Shelf to the Bottom  Plate.  4 Screws 17364   3. Remove the Keyboard Shelf from the Bottom Plate.  17365  ...
  • Page 6 7401-K568 4. Release the Cable Chain from the Cable Chain Bracket by lifting up  on the last link in the Cable Chain and pivoting it out.  1. Lift Up 2. Pivot Out Cable Chain Bracket   18523...
  • Page 7 7401-K568 5. Install the Keyboard. The Keyboard installation procedures vary,  depending on which keyboard you have.   2336‐K020, 2336‐K100 or 2336‐K634 Cherry Keyboard w/Trackball   a. Insert the Keyboard into the Keyboard Shelf.  18524...
  • Page 8 7401-K568 b. Using a nut driver, install the two Keyboard Locking Brackets.  Locking Bracket 22579...
  • Page 9 7401-K568 c. Route the Keyboard Cable through the channel in the Keyboard  Shelf and then install a Strain Relief Bushing.  Strain Relief Bushing 18526   d. Proceed to Step #6. ...
  • Page 10 7401-K568 2336‐K212 Rugged Keyboard w/Trackball  Note: The 2336‐K212 Rugged Keyboard requires the Rugged  Keyboard Mount kit (7402‐K569) in order to install the keyboard on  the mount. This kit includes everything shown below except the  keyboard.  a. Insert the Gasket into the bottom of the Rugged Keyboard  Housing.  b. Insert the Rugged Keyboard into the bottom of the Rugged  Keyboard Housing.  c. Install the two Rugged Keyboard Clamps (four nuts each).  Caution: Evenly tighten the nuts before applying the final  torque to secure the Rugged Keyboard Clamps. DO NOT over  tighten the nuts as this can deform the Rugged Keyboard  Housing.  Rugged Keyboard Housing Gasket Rugged Keyboard Rugged Keyboard Clamp (2) Nut, 6-32 Keep Lock (4)   22570b...
  • Page 11 7401-K568 d. Install the Keyboard Assembly onto the Keyboard Shelf and  secure it with screws (4).  Keyboard Assembly Keyboard Shelf 22571  ...
  • Page 12 7401-K568 e. Route the Keyboard Cable through the channel in the Keyboard  Shelf and then install a Strain Relief Bushing.  Strain Relief Bushing 18526  ...
  • Page 13 7401-K568 6. Route the Keyboard Cable through the Cable Chain Bracket and  then connect the Cable Chain onto the Cable Chain Bracket.  Cable Chain Bracket Cable Chain Bracket Screws   18527...
  • Page 14 7401-K568 7. Route Keyboard Cable through the split side of the Cable Chain  links.  Push Cable Into Chain 18528  ...
  • Page 15 7401-K568 8. Extend the Mounting Plate fully forward.  9. Route the Keyboard Cable through the Mounting Bracket.  10. Slide the Keyboard Shelf onto the Bottom Plate and install the four  screws.  11. Connect the Cable Chain to the Cable Chain Bracket.  Cable Chain Bracket   18529...
  • Page 16 7401-K568 12. Install a Strain Relief Bushing in the Mounting Bracket.  Strain Relief Bushing 18530  ...
  • Page 17: Installing The Mounting Bracket

    7401-K568 Installing the Mounting Bracket Secure the Mounting Bracket to a wall with lag screws or with  hardware of similar strength. The recommended viewing height for the  terminal is 1.2 m (48ʺ) from the floor.  Lag Screws (6) Wall Bracket 1.2 m (48 in) Recommended Height from Floor 17351  ...
  • Page 18 7401-K568 Installing the Fixed-Angle Mount 1. Mate the slots in the back of the Fixed‐Angle Mount onto the  locking tabs on the Mounting Bracket.  2. Secure the Fixed‐Angle Mount with the two supplied screws.  18531  ...
